SB103C-L25 5.0M Pixels USB Camera Module With 2.5mm Board Lens

SB103C-L25 5.0M Pixels USB Camera Module With 2.5mm Board Lens thumbnail-1
SB103C-L25 5.0M Pixels USB Camera Module With 2.5mm Board Lens photo-1
US$ 40 - 80 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Brand Name:
LIDA
Model Number:
SB103C-L25
High Definition Support:
1080P (Full-HD)
Contact Supplier Request Quote Chat Now
Lida Optical And Electronic Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name LIDA
Model Number SB103C-L25
High Definition Support 1080P (Full-HD)
Media Type HDD / Flash Memory
Place of Origin Henan, China

Specifications

USB camera module
1.High speed USB 2.0 interface;
2.5.0MP CMOS sensor for high quality image
3.High frame rate.
4.With UVC.

General Description



The HD USB2.0 CMOS board camera module(model:SB103C-L25) is ideal for many



applications like security systems, portable video system,video phones, industrial



machine monitoring and toys. It use high quality image sensors made by MICRON,



one of the world leaders in this fieldof electronics.



The HD USB2.0 camera module is not designed as consumer items but are ideal forequipment manufacturers, experimenters and hobbyists.





Applications



Car and ship control, electrical equipment,oil field equipment,industrial equipment, remote site monitoring, environmental monitoring, etc.



Features





5.0MP CMOS sensor for high quality image and low power consumption.

High speed USB 2.0 interface for high resolution PC camera interface.

Active pixel technology for sharp image and accurate color reproduction.

Superior low light performance – ideal for any lighting condition.

Super small outline and thin profile for embedded applications.

High frame rate

High quality lens for true to life undistorted color image.

Bus powered with low power consumption – ideal for portable equipment.

UVC for use in Linux, Windows XP SP2 or above.

Camera with UVC.



Parameters



Image Sensor

1/2.5”(4:3) Color CMOS image sensor



DSP

Vimicro chip



 Effective Pixels

160x120, 176x144, 320x240, 352x288, 640x480, 800x600, 1280x1024, 1600x1200, 2048x1536,2592x1944



 Signal Output

Serial data for USB standard compliant 2.0 and 1.1



Output format

YUV/M-JPEG ,BMP/JPG AVI/WMV



Frame Rate

deliver 30 fps in VGA, 15fps in QXGA



Operating System

O/SWindows XP , VISTA,win7 and Linux



UVC

Linux, Mac, Windows XP SP2 or above



Operating temperature

-30°C-65°C



Power Consumption

50mA



Dimensions (mm)

32mm*32mm

Board Layout

SB103C-L25 5.0M Pixels USB Camera module with 2.5mm board lensSB103C-L25 5.0M Pixels USB Camera module with 2.5mm board lensSB103C-L25 5.0M Pixels USB Camera module with 2.5mm board lens













USB Interface

Connecting the Device to USB

Pin-outs:

SB103C-L25 5.0M Pixels USB Camera module with 2.5mm board lens
