OBT-7065 19 Inch proffessional high Power Amplifier with one channel for PA system
Application:
Used for every public place: Shopping center, School, Airport, Raillway stataion, Building, Mining pool,
Residential area, highway, toll plaza,Factory,Supermarket,Parking,Stadium,Mountain etc.
Features:
Standard Rack Design (2U),humanized design, sophisticated technology, filling with the high-grade temperament;
4 channels of LINE balanced × LR inputs, 4 channels of LINE balance × LRcascade outputs;
Panel with volume control knob;
The device has a good short circuit, overheat, overload automatic detect and protect function, the indicator will light to warm, warning buzzer will ring to alarm;
2 kinds of power output modes: constant voltage output 100V, 70V and constant resistance output 4~16Ω.
Technical parameters:
Model |
OBT-7035 |
OBT-7045 |
OBT-7055 |
OBT-7065 |
||
Rated Power Output |
350W |
450W |
550W |
650W |
||
Speaker Outputs |
70V, 100V & 4~16Ω |
|||||
Input Sensitivity & Impedance |
±385mV/10KΩ, balanced ×LR Input Screw |
|||||
Output Sensitivity & Impedance |
±385mV/10KΩ, balanced ×LR Output Screw |
|||||
Overload Electromotive Force |
>15dB |
|||||
Frequency Response |
50Hz~16KHz(+1dB, -3dB ) |
|||||
S/N Ratio |
>90dB |
|||||
THD |
Less than 0.5% at 1KHz, 1/3 rated power |
|||||
Ground Lift |
Lift the earth line ground by switch GND/lift to "lift" position |
|||||
Cooling |
Forced air from front to rear, start built-in fan when radiator temperature reaches 45 degrees |
|||||
Protection |
Over heat, over load & short circuit |
|||||
Power Supply |
AC220V/50Hz |
|||||
Power Consumption |
700W |
950W |
1200W |
1600W |
||
Weight |
16.83Kgs |
17.48Kgs |
19.19Kgs |
20.02Kgs |
||
Dimension |
525×525×170mm |
|||||
Material |
Black aluminum panel, SPCC cold rolled chassis |
|||||
Lead time:
Sample: In stock
Mass production: 5 working days
Company Pictures 1 for office:
Company Pictures 2 for workshop:
Certification 1 for License and Pantents:
Certification 2 for Products:
Real Projects Connection Diagram:
