Polyester Film

Name: Polyester Film
Brand: JADE
SKU: 111421799
Availability: InStock

US$ 1,500 - 2,500 MOQ: 1 Metric Ton

Key Specifications

Material:

PET

Type:

Stretch Film

Usage:

Other, various electronic and electrical applications

Jiangsu Sanfangxiang Group Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

zhangjiagang china jiangyin china shanghai china

Delivery Detail:

Delivery time depends on order quantity.

Material PET

Type Stretch Film

Usage Other, various electronic and electrical applications

Feature Moisture Proof

Processing Type Casting

Transparency Translucent

Place of Origin Jiangsu, China

Brand Name JADE

Model Number MA

Specifications

1)High tensile strength
2)Good toughness
3)Excellent chemical resistance
4) Electric insulation

Specifications:

Thickness(μm):23~75

Width(mm):380~2000

Roll ID(mm):152

Characteristic feature:

1)High tensile strength

2)Good toughness

3)Excellent chemical resistance

4) Electric insulation

Usage:

Be used for electrical insulation, such as slot insulation, interphase insulation and liner insulation in

electric motor, wrapping insulation for coils and cables, as well as producing insulation flexible

composite material.

Typical property values:

Item	Units	Typical values	Test method
Nominal thickness	um	25	DIN 53370
Thickness Deviation	%	±1.5	ASTM D 374
Tensile strength(MD/TD)	MPa	210/210	ASTM D 882
Elongation(MD/TD)	%	160/150	ASTM D 882
Heat shrinkage(MD/TD)150°c,30min	%	1.6/0.3	ASTM D 1204
Haze	%	3	ASTM D 1003
Gloss	%	125	ASTM D 2457
Surface wetting tensions corona discharge	Dyne/cm	52	ASTM D 2578
No corona discharge		44
Note: MD=machine direction,TD=transverse direction. This specification is typical product information.The results should only be interpreted as a general guide to material properties,not as a guarantee.Certificates of analysis are available upon customer request.
