Advanced PC400X600 Capacity 8tons To15tons per Hour Mining Hammer Crusher,hammer Mill
Advanced PC400X600 capacity 8tons to15tons per hour mining hammer crusher,hammer mill
Advantages of hammer crusher
1.High production and high crushing ratio.
2Low power consumption, homogeneous particle size.
3.Simple, compact and light mechanical structure.
4.Low investment cost, easy management.
Hammer crusher Description:
hammer mill machine is applicable for both dry and wet crushing.grinder hammer mill machine is widely used for medium or fine crushing for medium hard and brittle materials by departments of mine, cement, coal,building material, metallurgy, chemical industry, road construction,gas chemical industry and thermal power generation, etc. Coal gangue,coke, slag, limestone, phosphate rock, salt, whiting, gypsum stains,alum, brick and tile, etc. can be crushed by this equipment. The compression strength of the materials shall not exceed 100MPa, while the moisture content shall be lower than 15%.
Application of hammer crusher
Hammer crusher is mainly suitable for crushing various soft and medium-hard ore, whose compression strength is not higher than 320MPa, such as coal, salt, chalk, gypsum, blocks, limestone, glasses, and phosphate, etc.
This grinder hammer mill machine can be also used for crushing chips and paper with fiber structure and strong elasticity and ductility, or recycling asbestos fiber by crushing wastes of asbestos cement, etc. Gap between the gratings areadjustable to change grain size of the discharge, so as to meet different requirements of the customers.
The technical parameters of Hammer crusher
Model | Rotor Diameter (mm) | Roter Length (mm) | Hammer Quantity | Max Feeding (mm) | Discharging (mm) | Capacity (t/h) | Power (kw) | Motor Model | REV (r/min) | Machine Size (mm) |
PC300×400 | 400 | 300 | 16 | <100 | <15 | 3-8 | 11 | 1100 | 855×795×862 | |
PC400×600 | 600 | 400 | 20 | <150 | <15 | 8-15 | 18.5 | 1000 | 1155×1100×1255 | |
PC600×800 | 800 | 600 | 28 | <220 | <20 | 15-30 | 45 | 900 | 2360×1500×1580 |
