Specifications
Subminiature in size and pitchPositive locking between housing and header which is easy to handle and secure
Many applications require a wire-to-board connector that is sub-miniature in size but offers many of the attributes of connectors larger in size.
The GVH Series wire-to-board connectors are on a 1.25mm (.049”) pitch, molded in a 94V0 PBT, SMT compatible, polarized and have a secure positive locking feature including an audible click and tactile feedback, when mated.
The series has an operating temperature range of -25 C to +85C including temperature rise when applying an electrical current.
The series is offered in 2~15 pin sizes.
crimp style wire-to-board connector series
single row crimp style wire-to-board connector series is available in 2 through 15 holes.
The series is rated at 1.0 amp AC/DC using a 26AWG wire,
has a rating of 50 volts AC/DC and
operates in a temperature range of -25 degrees centigrade to +85 degrees centigrade.
The GVH single row crimp style wire-to-board contacts will accommodate a wire range of 30 to 26 AWG . Contacts are tin plated brass providing for a very reliable contact interface and cost effective solution.
