Ultra-thin C35-W1V 24v Led Power Supply Factory

Name: Ultra-thin C35-W1V 24v Led Power Supply Factory
Brand: Sanpu
SKU: 111390237
Availability: InStock

Shenzhen Sanpu Intelligent Technology Co., Ltd.

US$ 5.5 - 12.5 MOQ: 10 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Sanpu

Model Number:

C35-W1V

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Sanpu

Model Number C35-W1V

Output Power 1 - 50W

Output Type Single

Input Voltage 110V

Output Voltage 24V

Output Frequency 50HZ

Output Current 1.5A

Specifications

1.100% full-load
2.High quality and competitive price
3. Specialized in Switching led Power Supply
4.2 years warranty

Ultra-thin C35-W1V 24v Led Power Supply factory

specification:

Model		C35-W1V5	C35-W1V12	C35-W1V15	C35-W1V24
output	DC voltage	5V	12V	15V	24V
	Voltage tolerance	±1%	±1%	±1%	±1%
	Current range	0~5A	0~3A	0~2.4A	0~1.5A
	Rated power	35W	35W	35W	35W
	DC voltage ADJ.range	±10%	±10%	±10%	±10%
input	Voltage range	85~264VAC(selected by switch)
	frequency	47~63HZ
	AC current	0.9A/110V,0.45A/230VAC
	efficiency	76%	80%	76%	80%
	Inrush current	Cold start current 30A/230VAC
	Leakage current	< 1mA/240VAC
protection	overload	Rated output power105%~135% start over load protection
		protection type:cutoff output,recovery after restart power
	over-voltage	105~135% hiccup mode,auto-recovery
	-----	-----
		-----
environment	Working temp,humidity	-10°C~+60°C,20%~90%RH
	Storagetemp,humidity	-20°C~+85°C,10%~95%RH non-condensing
	Withstand vibration	10~500HZ,2G 10min/1cycle,period for 60 minutes,each axes
safety	Withstand voltage	I/P-O/P:1.5KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC
	Isolated resistance	I/P-O/P,I/P-FG,O/P-FG:100M ohms/500VDC
Fitstandard	Safety standard	Fit UL1012
	EMC standard	Comply with EN55022,UL60950
	Weight/packing/size	0.15kg/80pcs/12kg/805933(mm)
note	1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25°C of ambient temperature. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor. 3. Tolerance : includes set up tolerance, line regulation and load regulation
