Constant Current Spannungsversorgung, China IP67 Constant Current Spannungsversorgung Manufacturer,supplier & Exporter
US$ 1 - 16
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
SANPU
Model Number:
LP35-W1A700
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Distribution Waterproof High Quality Led Driver 20w 350MA 700MA Current Transformer for Led LightingUS$ 5 - 15MOQ: 5 Pieces -
Distribution Waterproof Power Led Driver 700ma 20w 350MA 700MA Current Transformer for Led LightingUS$ 5 - 15MOQ: 5 Pieces
-
Distribution Waterproof Meanwell Driver Led Street Light 20w 350MA 700MA Current Transformer for Led LightingUS$ 5 - 15MOQ: 5 Pieces
-
Distribution Waterproof Led Downlight Driver 20w 350MA 700MA Current Transformer for Led LightingUS$ 5 - 15MOQ: 5 Pieces
-
Distribution Waterproof Led Driver Plug 20w 350MA 700MA Current Transformer for Led LightingUS$ 5 - 15MOQ: 5 Pieces
Place of Origin
Guangdong, China
Brand Name
SANPU
Model Number
LP35-W1A700
Output Power
1 - 50W
Output Type
Single
Input Voltage
220V
Output Voltage
10~48V
Output Frequency
50~60Hz
Output Current
700mA
Specifications
china IP67 constant current spannungsversorgungOEM&ODM welcome
universal AC input
Good for led lights,atx,etc
China IP67 Constant Current Spannungsversorgung
Brief
· new IP67 constant current power supply ;
· Good for led lights, cctv,atx,lcd tv, led display etc;
· OEM & ODM are welcome;
· Long lifespan, can be 50,000h;
· Various tyepes, convenient wiring;
· Universal AC input;
· 100% full load burn-in test;
· Built-in EMI fiter with tiny ripple;
· High operating temperature up to 60°C;
· Protection: short circuit/over load/over temp/over voltage/over temp;
· High efficiency, long life and high reliability.
| LP50-W1A1400/1750 | |||
| MODEL | 1400mA 50W | 1750mA 50W | |
| OUTPUT | DC CURRENT | 1400mA 50W | 1750mA |
| RATED VOLTAGE | 9~35V | 9~32V | |
| RATED POWER | 50W | ||
| SETUP.RISE TIME | 200ms 100ms | ||
| HOLD UP TIME(Typ.) | 30ms | ||
| INPUT | VOLTAGE RANGE | 100-240VAC | |
| FREQUENCY RANGE | 50/60HZ | ||
| POWER FACTOR(Typ.) | PF>0.6/220VAC | ||
| EFFICIENCY(Typ.) | ≥80% | ||
| INRUSH CURRENT(Typ.) | COLD-START CURRENT30A/230VAC | ||
| PROTECTION | Short circuit | Protection Type:recovers automatically after fault condition is removed | |
| Overlaod | 102%~107% hiccup mode,auto-recovery | ||
| Over temperature | ≥105%°C hiccup mode,auto-recovery | ||
| ENVIRONMENT | WORKING TEMP. | -20°C~+60°C | |
| WORKING HUMIDITY | 20%~90%RH | ||
| STORAGE TEMP.HUMIDITY | –40°C~85°C/10%~95%RH | ||
| SAFETY&EMC | SAEFTY STANDARDS | CE ROHS AND IP67 | |
| WITHSAND VOLTAGE | I/P-O/P:1.5KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC | ||
| EMC Test Standards | EN55015:2006;EN61547:1995+A1:2000;EN61000-3-2:2006; | ||
| EN61000-3-3:1995+A2:2005;EN61347-1:2001;EN61347-2-13:2006 | |||
| WEIGHT | 0.35Kg,80pcs/27Kg | ||
| NOTE |
1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25°C of ambient temperature. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor. 3. Tolerance : includes set up tolerance, line regulation and load regulation |
||
