80w Waterproof Power Supply

80w Waterproof Power Supply thumbnail-1
80w Waterproof Power Supply photo-1
US$ 3 - 20 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
SANPU
Model Number:
LP80-W1V
Contact Supplier Request Quote Chat Now
Shenzhen Sanpu Intelligent Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name SANPU
Model Number LP80-W1V
Output Power Other, 80w
Output Type Single
Input Voltage Other, 85~264VAC
Output Voltage 24V
Output Frequency 47-63Hz
Output Current 4.2a

Specifications

80w waterproof power supply
1.output:80w 24v
2.AC universal input
3.two years warranty
4.CE&ROHS



Specification



SPECIFICATION
MODEL 12V 80W 15V 80W 24V 80W 48V 80W
OUTPUT DC VOLTAGE     12V      15V     24V    48V
RATED CURRENT       8.5A     6.7A    4.2A    2.0A
CURRENT RANGE    0~8.5A    0~6.7A    0~4.2A 0~2.0A
RATED POWER     80W      80W   80W    80W
RIPPLE& NOISE (MAX.)NOTE2    100mV    100mV    150mV    150mV
VOLTAGE TOLERANCENOTE3      ±1%      ±1%      ±1%      ±1%
SETUP , RISE TIME 200ms/220VAC 100ms/220VAC
HOLD UP TIME(Typ.) 30ms/VAC
INPUT VOLTAGE RANGE 85~264VAC
FREQUENCY RANGE 47~63Hz
POWER FACTOR(Typ.) PF>0.6/220VAC
EFFICIENCY(Typ.) 85% 85% 87% 87%
AC CURRENT(Typ.) 1.8a/110V,1A/230V
INRUSH CURRENT(Typ.) cold start 40A/230V
short circiut protection type: recovers automatically after fault condition is removed
PROTECTION Over load 115~135% hiccup mode, auto-recovery
over temp ≥85%°C cut off the output, auto-recovery
ENVIRONMENT WORKING TEMP -20°C~+60°C(no frost)
WORKING HUMIDITY 20%~90%RH
STORAGE TEMP , HUMIDITY –40°C~85°C/10%~95%RH
SAFETY &EMC SAFETY STANDARDS CE ROHS IP67
WITHSTAND VOLTAGE
I/P-O/P: 1.5KVAC/1min, I/P-F/G: 1.5KVAC/1min, O/P-F/G: 0.5KVAC/1min
EMC Test Standards EN55015:2006; EN61547:1995+A1:2000;EN61000-3-2:2006
EN61000-3-3:1995+A2:2005;EN61347-3-13:2006
NOTE 1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25°C of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation







80w waterproof power supply



Remark: input or output voltage &frequency can be adjustable as per the customer's request, customized order is acceptable. Please contact us.



80w waterproof power supply



Key features



1.universal AC input

2.Protections: short circuit, over load, over temp, over voltage

3.Build-in EMI filter with tiny ripple

4.100%full load burn-in test

5.Small volume high-efficiency

6.Conform to EN60950 GB4943 UL60950 safety standards

7.Conform to GB9254, EN55022,EMC standards



Application



1.Office lighting, artworking lighting, display case

2.Home lighting hotel, restaurant light and so on.

3.Commercial lighting such as: downlight, panel light, spotlight,wall washer.

4.other public lighting.





CE & ROHS





80w waterproof power supply



 Remark: we can stick customer's label as long as you can purchase enough quantity

               in a time.



How to order



1. Let me know the models, quantities, parameters you want to order.



2. We will email you the Proforma Invoice based on your order for your information.



3. Please check the PI carefully, confirm everything is right,

   and then we will deliver the goods when we received your payment.

   Besides,the shipping cost is depending on the weight.



Payment



1. We accept T/T (30% deposit, 70% before loading)



2. If you prefer other pay ways, please let us know

Shipment



Shipment



We choose the cheapest and safest shipping company for you.

We have cooperated with DHL, UPS and TNT for long time.

DHL, UPS, TNT are our prior express.





 After services



1. Your inquiries will be replied in 24hours.

2. We provide two years warranty of quality after sale.

3. OEM & ODM are available.

4.Track the order until you get the goods.



Why choose us?



1.We are factory, can offer your competitive picture.

2. 8 years focus on the LED Power Supply Research and development, Production;

3. High reliability and good stability, for many kinds of large-scale outdoor lighting project, through the use of test from 3000 customers





80w waterproof power supply80w waterproof power supply
