Home > Electrical & Electronics > Power Supply & Distribution > Switching Power Supply > CE ROHS 350W 12v Led ac dc Switching Power Supply
US$ 2 - 27
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
SANPU
Model Number:
FX350-H1V12
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
220v dc 12v Transformer China Manufacturer&supplier&exporterUS$ 10 - 15MOQ: 1 Piece -
CE ROHS 150W 12V ac dc Waterproof Power SupplyUS$ 2 - 19MOQ: 1 Piece
-
12v to 24v dc Converter China Manufacturer&supplier&exporterUS$ 10 - 15MOQ: 1 Piece
-
SANPU CE ROHS Approved FX 250W 12V ac dc Switch Waterproof Power SupplyUS$ 2 - 23MOQ: 1 Piece
-
SANPU CE ROHS Approved 400W 12V ac dc Switch Waterproof Led Power SupplyUS$ 2 - 28MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
SANPU
Model Number
FX350-H1V12
Output Power
201 - 300W
Output Type
Single
Input Voltage
220V
Output Voltage
12V
Output Frequency
47-63HZ
Output Current
0-29A
Specifications
350W 12v led ac dc switching power supplyCertificates: ROHS ,CE
Life span:50,000h
2 years warranty
Features:
1. 350W 12v led ac dc switching power supply .
2. The product consists of indoor type and outdoor type.
3. Convenient wiring.
4. Abnormality protection function : short circuit ,over load ,over voltage,over temp .
5. Various types for your choice:Constant Voltage Power supply and Constant Current Power supply.
6. Quality assurance: 2 years warranty.
7 High efficiency .
8.International AC input .
9.Built-in EMI fiter .
10.100% full load burn-in test .
FX Waterproof type FX350-H1V | |||||||
| MODEL | 5V 350W | 12V 350W | 15V 350W | 24V350W | 27V 350W | 48V 350W | |
| OUTPUT | DC VOLTAGE | 5V | 12V | 15V | 24V | 27V | 48V |
| RATED CURRENT | 70A | 29A | 23.2A | 14.6A | 13A | 7.3A | |
| CURRENT RANGE | 0~70A | 0~29A | 0~23.2A | 0~14.6A | 0~13A | 0~7.3A | |
| RATED POWER | 350W | 350W | 350W | 350W | 350W | 350W | |
| RIPPLE& NOISE (MAX.)NOTE2 | 150mV | 150mV | 150mV | 150mV | 150mV | 200mV | |
| VOLTAGE TOLERANCENOTE3 | ±2% | ±1% | ±1% | ±1% | ±1% | ±1% | |
| SETUP , RISE TIME | 200ms/220VAC 50ms/220VAC | ||||||
| HOLD UP TIME(Typ.) | 20ms/220VAC | ||||||
| INPUT | VOLTAGE RANGE | 170~264VAC | |||||
| FREQUENCY RANGE | 47~63Hz | ||||||
| POWER FACTOR(Typ.) | PF>0.6/220VAC | ||||||
| EFFICIENCY(Typ.) | 81% | 84% | 84% | 85% | 86% | 87% | |
| AC CURRENT(Typ.) | 4A/230VAC | ||||||
| INRUSH CURRENT(Typ.) | COLD START 50A/230VAC | ||||||
| PROTECTION | Short circuit | Protection type : recovers automatically after fault condition is removed | |||||
| Over load | 105~135% hiccup mode , auto-recovery | ||||||
| Over voltage | 115%~135% Cut off the output , auto-recovery | ||||||
| Over temperature | Rectifier ≥90°C cut off the output , auto-recovery | ||||||
| ENVIRONMENT | WORKING TEMP | -20°C~ +60°C | |||||
| WORKING HUMIDITY | 20%~90%RH | ||||||
| STORAGE TEMP , HUMIDITY | -40°C~+85°C,10%~90%RH | ||||||
| SAFETY &EMC | SAFETY STANDARDS | CE,ROHS | |||||
| WITHSTAND VOLTAGE | I/P-O/P:1.5KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC | ||||||
| EMC Test Standards | Conform to EN60950 GB4943 UL60950 Safety standards | ||||||
| Conform to GB9254 EN55022 EMC standards | |||||||
| NOTE | 1.All paraments NOT specially mentioned are measured at 220VAC input ,reted load and 25°C of ambient temperature 2.Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1 uf & 10 uf parallel capacitpr . 3.Tolerance : includes set up tolerance , line regulation and load regulation . | ||||||
