Help CenterSANPU Hot Selling CE ROHS ac dc Switch 12w 700ma Switching Power Supply
Related Products
-
SANPU 2013 New Arrival CE ROHS PY 3W 350mA Constant Current ac dc Switch Mode Electronics Power Supply Led Driver China SupplierUS$ 1 - 3MOQ: 1 Piece -
SANPU CE ROHS OEM PY 12W 350mA Constant Current Electric Power SupplyUS$ 1 - 7MOQ: 1 Piece
-
CE ROHS 25w Atx Power Supply, Computer Power Supply, dc Power Supply 350ma Supplier & Manufacturer & ExporterUS$ 1 - 9MOQ: 1 Piece
-
CE ROHS 25w pc Power Supply, Computer Power Supply, dc Power Supply 350ma Supplier & Manufacturer & ExporterUS$ 1 - 9MOQ: 1 Piece
-
25w 350ma Switch Mode Power Supply, Switching Power Supply, Light Driver Supplier & Manufacturer & ExporterUS$ 1 - 9MOQ: 1 Piece
Specifications
ac dc switch 700ma switching power supplyInternational AC input
100% full load burn-in test
Built-in EMI filter
PF:0.92
SANPU hot selling CE ROHS ac dc switch 12w 700ma switching power supply
Feathers:
1. Universal AC input / Full range;
2. 100% full load burn-in test;
3. Built-in EMI fiter with tiny ripple;
4. High efficiency, high qulity, long life and high reliability;
5. Abnormality protection function : short circuit ,over load ,over voltage,over temp;
6. Convenient wiring;
7. The product consists of indoor type and outdoor type;
8. Various types for your choice:Constant Voltage Power supply and Constant Current Power supply.
| MODEL | 350mA12W | 700mA12W | |
| OUTPUT | DC CURRENT | 350mA | 700mA |
| RATED VOLTAGE | 24~44V | 9~15V | |
| RATED POWER | 12W | 12W | |
| SETUP.RISE TIME | 200ms 100ms | ||
| HOLD UP TIME(Typ.) | 30ms | ||
| INPUT | VOLTAGE RANGE | 100-240VAC | |
| FREQUENCY RANGE | 50/60HZ | ||
| POWER FACTOR(Typ.) | PF>0.6/220VAC PF:0.92 | ||
| EFFICIENCY(Typ.) | ≥80% | ≥80% | |
| INRUSH CURRENT(Typ.) | COLD-START CURRENT15A/230VAC | ||
| PROTECTION | Short circuit | Protection Type:recovers automatically after fault condition is removed | |
| Overlaod | 115%~135% hiccup mode,auto-recovery | ||
| Over temperature | ≥105%°C hiccup mode,auto-recovery | ||
| ENVIRONMENT | WORKING TEMP. | -20°C~+60°C | |
| WORKING HUMIDITY | 20%~90%RH | ||
| STORAGE TEMP.HUMIDITY | –40°C~85°C/10%~95%RH | ||
| SAFETY&EMC | SAEFTY STANDARDS | CE ROHS AND IP60 | |
| WITHSAND VOLTAGE | I/P-O/P:1.5KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC | ||
| EMC Test Standards | EN55015:2006;EN61547:1995+A1:2000;EN61000-3-2:2006; | ||
| EN61000-3-3:1995+A2:2005;EN61347-1:2001;EN61347-2-13:2006 | |||
| OTHER | Dimension | 70*34(mm) | |
| weight/packing | 0.08kg,200pcs/16kg | ||
| NOTE |
1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25°C of ambient temperature. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor. 3. Tolerance : includes set up tolerance, line regulation and load regulation |
||
Q: What the power supply can be used for ?
A: Good for led lights,cctv,atx,lcd tv,lg tv,etc.
SHENZHEN SHANPU INTLLIGENT TECNOLOGY CO., LTD. is special power supply Manufacturer. Our factory specializes in switching power supply. Switching power supply can be used for strip light, point source, led hurdle lamp, flash light,light bulb, led COB ceiling light, led downlight, led spotlight, etc.
·8 years driver/power supply experience with rich research and development
department;
· We accept ODM and OEM based on clients' needs;
· Accept any transportation ways;
· Sustainable techincal supporting and assistance;
· 2 years warranty;
· CE&ROHS,Conform to EN60950 GB4943 UL60950 Safety standards, Conform to GB9254 EN55022 EMC standards;
·Your inquiry related to our products or prices will be replied in 24hrs;
·Welltrained and experienced staffs to answer all your enquiries in fluent English.
Trade Terms
1.Payment:T/T,Paypal in advance,(Other payment can be negotiated );
2.Production lead time: 7-15 days;
3.Sample can be delivered in 5-7 days;
4.Shipping freight are quoted under your requests;
5.Shipped:DHL, Fedex, UPS, TNT;
6.Discounts are offered based on order quantities.
