Help Center130series 32 Spindle 1 Head Marine Ropes ,asbestos Rope,double Strand Wrapping Cable Braiding Machine XD13O-32-1
Related Products
-
Skipping Rope Braiding MachineUS$ 3,500 - 4,500MOQ: 1 Set -
Servo Motor on Take up 130 Series 16 Spindle Skipping Rope Braiding Machine PriceUS$ 3,500 - 4,500MOQ: 1 Set
-
Servo Motor on Take up 130 Series 16 Spindle Bungee Cord Braiding Machine PriceUS$ 3,500 - 4,500MOQ: 1 Set
-
130 Series 16 Spindle Climbing Rope Braiding Machine PriceUS$ 3,500 - 4,500MOQ: 1 Set
-
130 Series 16 Spindles High Speed PLC Rope Braiding MachineUS$ 3000.00 - 3000.00MOQ: 1 Set
Application of braiding products:
High strength cables, fire ropes, mountaineering ropes, marine ropes, safety ropes, and etc..
Range of braiding materials:
All flexible fibers, yarns, belts, threads
Control system:
- Frequency inverter controlled production speed.
- Yarn broken sensor (if a yarn is broken or a bobbin is empty, the machine stops automatically)
- Speed set
- Control cabinet
Scope of supply:
- Machine with control system
- Operation and maintenance manual
- Tool box
- Wearing and sparing parts
- Training and trial operation
- Packing
Specifications
- Intellignrt control system and Reliability
- High quality and Factory,Cheap1
- Flexible Operation and High Poductivity
- CE,ISO9001
130 series 12spindle High Speed round rope , marine ropes ,asbestos rope,double strand wrapping cable braiding machine XD13O-32-1
| Model | Spindle Qty | Head Qty | Measurement(mm) | Power(kw) | Max.Horngear Speed(rpm) | Spindle Type | Bobbin Size(mm) |
| XD130-16-2 | 16 | 2 | 1520×950×1760 | 0.75 | 270 | B | Φ70×210 |
| XD130-24-1 | 24 | 1 | 1100×1100×1760 | 1.1 | 270 | B | Φ70×210 |
| XD130-32-1 | 32 | 1 | 1280×1280×1760 | 1.1 | 270 | B | Φ70×210 |
| XD130-40-1 | 40 | 1 | 1280×1280×1900 | 1.5 | 270 | B | Φ70×210 |
| XD130-48-1 | 48 | 1 | 1400×1400×1900 | 1.5 | 270 | B | Φ70×210 |
Product pictures:
contact:Alisa
mobile phone:+86-13916465059
whatsapp:+86-15110343262
wechat:+86-15110343262
skype:live:alisa_740
Address:NO.8,lane3841Huqingping Road,Qingpu district,Shanghai,201703,China.
