Home > Packaging & Printing > Printing Machinery > Digital Printing Machine > Docan Road Sign Flatbed Printer Building Index Printing Machine

Docan Road Sign Flatbed Printer Building Index Printing Machine

Name: Docan Road Sign Flatbed Printer Building Index Printing Machine
Brand: Docan
SKU: 111347769

Docan Road Sign Flatbed Printer Building Index Printing Machine thumbnail-1

Docan Road Sign Flatbed Printer Building Index Printing Machine photo-1

US$ 40,000 - 120,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Plate Type:

Flatbed Printer

Place of Origin:

Shanghai, China

Contact Supplier Request Quote Chat Now

Shanghai Docan Tech Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Plate Type Flatbed Printer

Place of Origin Shanghai, China

Brand Name Docan

Model Number M10

Usage Other

Automatic Grade Automatic

Voltage 220v

Gross Power 8kw

Weight 2160KG

Certification CE,CCC;ISO

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1. piezo electric print
2. UV lamp dry immediately
3.Vacuum and automatic height adjust
4. Konica 1024-14pl
5. CE; ISO

Company Profile Thanks for your inquiring our UV printers! Shanghai DOCAN technology is a professional UV flatbed printer leader in China . Established in 2005, now our products have been exported to more than 50 countries, suchas:USA,Brazil,Mexico,Chile,UK,Spain,Finland,Portugal,Italy,Czech,Turkey,Russia,Poland,Ukraine,Monglia,India,Philippines,Australia,Malaysia,Indonesia,Africa etc. Welcome your RFQ so that we can give you a specific introduction to help you find your desired modeL.
Application material: Printed materials could be: glass, ceramic, ceiling, aluminum sheet, wood MDF board, door sheet, metal panel, billboard, acrylic panel, plexiglass, paper board, foam board, PVC expansion board, corrugated cardboard; flexible materials such as PVC, canvas,building mesh, carpet, sticky note, reflective film, leather,vinyl etc
Application Areas: Decoration industry, glass industry, advertising industry, exhibition industry, packing industry, leather, logo printing industry, artware industry,home appliance panel(microwave,fridge,heater,etc), furniture industry,stationery field etc. We can provide the printer with excellent performance & competitive price. You will enjoy our one-stop service.
UV ink advantage: 1.Its instant dry feature that makes the graphic completely cured. 2.It is not easy to clog the print head. 3.environment-friendly ink. Characteristics: water-proof, anti-uv, heat-resistance.
	Docan uv flatbed printer				Hybrid uv printer		ROLL2ROLL printer
Application	Almost all the flat rigid and flex material(thickness≤100mm)				Both flat&roll material(thickness≤50mm)		roll material (thickness≤2mm)
Model	M6	M8	M10	UV1212	Hybrid2510	Hybrid3210	R3300	R5200
Printing size(m)	*2.51.25**	*2.51.80**	*2.053.20**	*1.201.20**	*2.5unlimited**	*3.2unlimited**	*3.2m unlimited**	*5.2m unlimited**
printhead Technology	drop-on demand piezo electric
printhead control	printhead temperature and voltage are software adjustable
Printhead type	Japan konica KM512/konica KM1024/Ricoh GEN5 for option
Printhead NO.	2/4/5/6/7/8/10/12/15/16 acc to print head type				8/10/12/14/16		8/10/12/14
Ink characteristic	UV curing ink
Ink type	Belgium Agfa
Ink reservior	Reliable on the fly while printing/1000ml
Color control	ICC based color, curves and density adjustment
Color option	Cyan,Magenda,Yellow,Black, Light Cyan, Light Magenda, White,Varnish
Printing resolution	*Up to 14401440 dpi**
Printing speed	Different print head different speed (pls consult me)
Life of printed	Outdoor more than 5 years; indoor more than10 years
File format	TIFF, JPEG, EPS, PDF, POSTCRIPT 3
RIP sofware	PhotoPrint/ Onyx / Caldera
Power supply	220V 50/60HZ (10%)
Power consumption	Less than 8KW
Operation environ	Temperature 20.C to 30.C; Humidity 40% to 60%
Warranty time	One year
Training	free of charge
Installation	We will send technician to customer workshop for installation and training
Notification	Docan always adopt world first class apare parts like Japan konica print head, Japan THK guid rail, Italy megadyne transmission belt, UK primarc uv lamp, Germany JENA grating scale, KNF air pump, US poll ink filter, Taiwan Delta or Japan Panasonic servo motor, also the air circulation and electric circuit system main parts are all from Japan SMC, OMRON, Taiwan TAC, France Schneider and Germany Simens for quality guarantee. We alomost do uv printer 10 years as Chinese uv printing machine professionalleader and we only do UV.
Contact	We are looking for agents in many countries. If interest pls contact me. Elva lee from Docan Cell:18221727181 skype: sld-elva Email: docan9 at

TECHNICAL DATA SHEET:
Model:	M10
Print Technology:	Drop-on-demand Piezo Electric
Printhead Type:	JAPAN KM1024MHB-14PL
Printhead No.:	CMYK+LC+LM+WHITE(7Printhead)
Printhead Controls:	Print head temperature & voltage are adjustable by software
Printing Size:	205cm x 320cm
Ink Characteristics:	UV curing ink
Ink Reservoir:	Refillable on the fly while printing/1000ml
Loating Mode:	Resto/Servo
RIP Software:	Photoprint10
File Format:	TIFF, JPEG, Postscript 3, EPS, PDF, and so on.
Resolution:	360 dpi x 360 dpi 360 dpi x 720 dpi
	720 dpi x 360 dpi 720 dpi x 720 dpi
	720 dpi x 1440 dpi 1440 dpi x 1440 dpi
Printing Speed:	In draft mode up than 60sq.m
	In standard mode up than 30sq.m
	In high resolution mode up than 15sq.m
Ink Type:	UV curing ink
Ink Color:	CMYK+LC+LM+WHITE(7colors)
Printing Materials:	Glass, ceramic tile, ceiling, aluminum sheets, wooden sheets, billboards, acryl sheets, KD board, Plexiglas, foam board & flexible media like wall paper, glistening film, canvas, carpet, leather, paper sheets, etc.
Heating System:	Standard (Front heater, Rear heater, Fan)
Color Retains:	Outdoor 2 years, indoor 10 years
Color Management:	ICC based color, adjustment curves, density adjustment
Power Supply:	AC220V 50/60HZ (10%) 16A
Working Conditions:	Temperature 20-28 degrees, Humidity 40% - 60%
Dimensions:	4.8m3.93m1.38m
Weight:	2160kgs
Packing:	Packed by solid wooden carton.
Trade terms:	FOB Shanghai
payment terms	T/T30%deposit,70%balance before shipment
