Konica 7 color high precision uv flatbed printer

Specifications

1. piezo electric print
2. UV lamp dry immediate
3.Vacuum and automatic height adjustment
4. Konica 1024-14pl
5. CE;

Company Profile

Thanks for your inquiring our UV printers!

Shanghai DOCAN technology is professional UV flatbed printer leaders in China .

Established in 2005, now our products have been exported to more than 30 countries, suchas:USA,Brazil,Mexico,Chile,UK,Spain,Finland,Portugal,Italy,Czech,Turke,Russia,Poland,Ukraine,Monglia,India,Philippines,Indonesia etc. Welcome your RFQ so that we can give you a specific introduction to help you find your desired modes.

Application material:

Printed materials could be: glass, ceramic, ceiling, aluminum sheet, wood board, door sheet, metal panel, billboard, acrylic panel, plexiglass, paper board, foam board, PVC expansion board, corrugated cardboard; flexible materials such as PVC, canvas, cloth, carpet, sticky note, reflective film, leather etc.

Application Areas:

Decoration industry, glass industry, sign industry, exhibition industry, rigid paperboard packing industry, leather, textile printing industry, artware industry, furniture industry etc.

Our machine can print material includes rigid sheets, such as glass, metal, acrylic, PVC board, MDF, and the flexible material, like film, leather, canvas, wall paper, ceiling paper etc.

We can provide the printer with excellent performance & competitive price. You will enjoy our one-stop service.

UV ink advantage:

Its instant dry feature that leaves the graphic completely cured. It is not easu to clog the print head

UV ink boasts fewer emissions than solvent inks which is more environmental friendly.

UV Ink Features

Ink Type: It's UV curing ink, environment-friendly ink.

Characteristics: water-proof, anti-uv, heat-resistance.

Printing samples life: 3 years outdoor, and 10 years indoor.

Ink Brand: Belgium AGFA

Can print on flexible material and rigid material

Machine Highlights:

Higher Speed Plus Higher Resolution:
Konica print head with 1024-14PL nozzle is used to support you with high speed printing and higher resolution(Max resolution can be up to 1440dpi*1440dpi)

Double circulation for white color

One small circulation is the circulation within the ink bottle. when the head cartridge stop, the circulation starts. The pump starts to stir the ink bottle.

One big circulation is the circulation from the ink sub tank to the ink bottle

Beside this , there will be automatic frequency flush on the print head set by the software.

In this way, the white clot on the print head can be get rid of .

Solid Mechanical machine structures
The X axial guide rail is imported from JAPAN THK and taiwan PMI . which is more stable than the belt transmission to prevent of the belt will get loose after half years usage. The Y axial we use double screw pole for transmission.

Material Automatic height testing function

The machine can test the material height automatically.

Print head protection system

Print head anti-crash system can protect the print head by stopping the head cartridge in case of print head crash.

All the model we have:

The maximum media thickness can up to 100mm.

The printing size of our machine is

UV2512 2.44*1.22m

UV2510 2.5m width , length is unlimited / roll to roll

M6 2.5*1.2m

M8 2.5*1.8m

M10 2.05*3.2m

Our company contact info:

Elva Lee

Skype: sld-elva

URL :



Technical Specification of Docan M8
Model	M8 UV Flatbed Printer
Printing Size	2.5m*1.8m
Working Platform	Vacuum sucking and automatic height adjustment system
Printhead	Konica Minolta 1024-14PL ( drop-on-demand piezo electric )
Printhead Control	Printhead temerature and voltage are adjustable in software
Drying System	U.K. Primarc Lamp ( curing ink instantly )
Ink Type	UV environmental protection ink
Ink Consumption	1 m2 printing consumes 10 ml ink, costing about 1 $
Printing Color	C M Y K + Lc Lm + W
RIP Software	PhotoPrint or Onyx or Caldera
Color Management	ICC based color, curves adjustment, density adjustment
Picture Format	TIFF, JPEG, EPS, PDF, POSTCRIPT 3
Resolution	720 dpi x 1080 dpi ( 6 Pass )
	720 dpi x 1440 dpi ( 8 Pass )
Printing Speed	6 Pass up to 21 sq.m/hr
	8 Pass up to 16 sq.m/hr
Printing Material	glass, wood, PVC, acrylic, MDF, aluminum, metal, leather, tile, etc.
Printing Artwork Life	Outdoor 5 years, indoor 10 years
Warranty	One year
Power Supply	50/60HZ AC220V > 30A
Working Condition	Temperature 20-28 degrees, Humidity 40% - 60%
Machine Size	4.63m*2.48m*1.47m
Printer Weight	1870kgs
Packing	Inner packed by anti-rain & anti-rust plastic bubble film; outer packed by solid wooden crate.
Installation	We will send technician to customer workshop to install machine and conduct training

 Searching for overseas agent
