STA heat resistant Aluminum titanate riser tube
Low-pressure die casting is a process in which molten metal is transported from a holding furnace via a riser tube into a mould. Riser tube is the critical part of the process. During traditional production, steel riser tube can not satisfy the requirements of continuous production and high quality, so aluminium titanate becomes ideal material of riser tube due to its low thermal expansion coefficient, good thermal shock resistance and no wetting by molten metal. Our aluminium titanate riser tube produced by german patent get long service life and its combination property can reach the international advanced level.
Specifications of aluminium titanate riser tube
♥ Excellent wear resistant
♥ Anti-corrosion
♥ Good Thermal shock resistance
♥ Long service life
♥ ISO9001:2000 Certificate
The aluminum titanate riser tube is the key part of the low pressure aluminum casting machine,the features are as following:
1,Excellent thermal shock resistance
2,No infiltration with the non-ferrous metal
3,Excellent wear resistance
4,Low thermal-expansion coefficient
5,The service life of the aluminum titanate riser tube can reach 60 days , can enhance the production efficiency and reduce the cost.
The characteristics of the products
Item |
Standard |
Unit |
Density |
3.2 |
g/cm3 |
Porosity |
3.8 |
% |
Bending strength |
50 |
MPa |
|
Thermal-expansion coefficient |
1.17 |
10-6/°C |
Heat-shock resistance |
Good |
|
The size of the products:
The outer dia(mm) |
The inner dia(mm) |
The length(mm) |
Φ78 |
Φ58 |
850 |
Φ100 |
Φ80 |
400 |
Φ120 |
Φ100 |
600,800 |
Φ130 |
Φ110 |
1063 |
Φ130 |
Φ100 |
750 |
Φ120 |
Φ70 |
1220 |
Φ120 |
Φ80 |
950 |
Φ100 |
Φ60 |
900 |
Φ114 |
Φ68 |
1100 |
Φ100 |
Φ60 |
970 |
Φ110 |
Φ63.5 |
900 |
Φ90 |
Φ61 |
850 |
Φ105 |
Φ75 |
1050 |
Φ120 |
Φ80 |
930 |
Add:We can produce different sizes according to the customers’ enquirement.
