Home > Packaging & Printing > Printing Machinery > Digital Printing Machine > UV Offset Printer Docan UV2518A (2.44m*1.8m , Konica M512-14pl /42pl)

UV Offset Printer Docan UV2518A (2.44m*1.8m , Konica M512-14pl /42pl)

UV Offset Printer Docan UV2518A (2.44m*1.8m , Konica M512-14pl /42pl) thumbnail-1
UV Offset Printer Docan UV2518A (2.44m*1.8m , Konica M512-14pl /42pl) photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Flatbed Printer
Place of Origin:
Shanghai, China
Contact Supplier Request Quote Chat Now
Shanghai Docan Tech Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Plate Type Flatbed Printer
Place of Origin Shanghai, China
Brand Name Docan
Model Number UV2518
Usage Other, all kinds of rigid and soft printers
Automatic Grade Automatic
Dimensions(L*W*H) 4.52*2.46*1.33m

Specifications

Priting size: 2.44m*1.8m.
KM-512-14PL/KM-512/42PL.
media thickness: 1-80mm.
Dry immediately .
SMC negative pressure system.

Model: UV2518

Print Technolog: Drop-on-demand piezo electric

Printhead type: KM-512-14PL/KM-512-42PL

Print head control: the temperature and voltage are software adjustable.

Ink characteristic: UV curing ink

Ink reservoir: Riffiable on the fly while printing /1000ml

Drying system: UV lamp

Color management: based on ICC color, curves and density adjustment.

Rip software: Photoprint 10

File format: tiff, jpeg, postcript 3, EPS, pdf

Power supply: 50/60Hz 220v (10%)>20A

Operation environment: temperature 20 to 28 degree

HUmidity: 40% to 60%

printing size: 2.44m*1.8m

Media thickness: 1-80mm

print head number: 4/5/6/7/8/10/12/16/15 pcs

Resolution: 360dpi*360dpi. 360dpi*720dpi.         720dpi*360dpi.720dpi*720dpi.720dpi*1440dpi.1440dpi*1440dpi

Printing speed: in draft mode up than 52 sq.m/hr. in standard mode up than 36 sq.m/hr

                         in high resolution mode up than 22sq.m/hr (8 heads)

                         in super resolution mode up than 12 sq.m/hr

Color: 4 colors (CMYK) or 6 colors (CMYK LC LM)   white &varnish can be optional

Outdoor life: 2 years (use DOCAN ink)

Loating mode: resto/ servo

Dimensions : 4.52*2.46*1.33m

Packing: plastic bubble film sealed anti rain and rust. outside: solid wooden carton packing

Weight :1300kgs

Note: it can also use Konica M 1024 head, it depends on your requirements.

UV offset printer Docan UV2518A (2.44m*1.8m , Konica M512-14pl /42pl)UV offset printer Docan UV2518A (2.44m*1.8m , Konica M512-14pl /42pl)UV offset printer Docan UV2518A (2.44m*1.8m , Konica M512-14pl /42pl)
