Specifications
Docan uv flatbed printer adopts Konica 512-14PL/42PL heads, supporting you high speed with teriffic resolution.uv flatbed printer uv2510
Features and specification of uv2510
1) perfect quality along with competitive Price
We are a manufacturer of uv curing printer and own factory in Shanghai city, China. We produce China best quality, and support customers with attractive and cometitive price.
2) high speed + high resolution
Konica 512-14PL/42PL head adopted. The printing speed can up to 28 sq.m/h by 8 pass with max 1440 dpi * 1440 dpi of resolution.
3) uv lamp drying System
Uv lamp installed, so that the uv printer machine guarantees your printing art dries immediately, so that improves your productivity.
4) more application for clients
Printed media: flat rigid material, like glass, ceramic tile, ceiling, aluminum sheets, wooden sheets, billboards, acryl sheets, KD board, Plexiglas, foam board, etc. And flexible media, such as wall paper, glistening film, canvas, carpet, leather, paper sheets...
Used in: decoration industry, glass industry, sign industry, exhibition industry, leather textile printing industry, etc.
Technical Data of Docan2510 uv printer | ||
Item Name |
uv flatbed printer |
|
Model |
uv2510 |
|
Print Technology |
Drop-on-demand Piezo Electric |
|
Working Platform |
Vacuum and roll to roll platform |
|
Print-head Type |
Konica 512-14PL /42PL |
|
Print-head No. |
4/5/6/7/8/10/12/15/16/24 pcs |
|
Printing Size |
2500mm width x unlimited length |
|
RIP Software |
Photoprint 6.1 |
|
Drying System |
UV lamp |
|
Resolution |
360 dpi x 360 dpi 360 dpi x 720 dpi |
|
720 dpi x 360 dpi 720 dpi x 720 dpi | ||
720 dpi x 1440 dpi 1440 dpi x 1440 dpi | ||
Printing Speed |
In draft mode up than 28 sq.m ( 4 heads ) |
|
In standard mode up than 18 sq.m ( 4 heads ) | ||
In high resolution mode up than 11 sq.m ( 4 heads ) | ||
Ink |
Ink Type |
UV curing ink |
Ink Color |
4 colors (C, M, Y, K) - 7colors (C, M, Y, K, LC, LM + W) |
|
|
Printing Materials (55mm thick max.) |
Flat rigid media: glass, ceramic tile, ceiling, aluminum sheets, etc. Flexible media like wall paper, glistening film, canvas, carpet… Media in roll: vinyl roll, banner roll, fabric reel, canvas reel… |
|
Printing Art Life |
Outdoor 5 years, indoor 10 years |
|
Power Supply |
AC220V 50/60HZ (10%) Max 30A |
|
Working Conditions |
Temperature 18-30 degrees, Humidity 40% - 70% |
|
Machine Size |
4890mm*1520mm*1810mm |
|
Printer Weight |
3125 kgs |
|
Packing |
By solid wooden carton |
|
of uv
