Large Format UV Flatbed PVC Printer
General Information:
1) Outdoor Large Format UV Printer
2) Konica Minolta printhead
3) Resolution from 360dpi*360dpi to 1440dpi*1440dpi
4) C,M,Y,K,LC,LM + White colors for any print-heads
5) CE Certificate
Main features:
1)Perfect Quality Along With Competitive Price
Since we are a few manufacturers of UV flatbed printer in China with many years production experience, we can provide the printer with excellent performance & direct price. You will enjoy our one-stop survice.
2)Higher Speed Plus Higher Resolution
Konica printhead with 512-14PL/42PL nozzle is used to support you with high speed printing and higher resolution(Max resolution can be up to 1440dpi*1440dpi
3)Ideal Transmission System
USB optical transmission, interference, to avoid printing garbage.
4)C,M,Y,K,LC,LM + White colors for your wide choice
You can choose above colors to match print-heads as you need. 4 printheads(C,M,Y,K);6(C,M,Y,K+2 Whites or C,M,Y,K,LC,LM);7(C,M,Y,K,LC,LM+W);8(CMYK+CMYK or CMYK,LC,LM+2Whites).....
5)More Application
Application areas includs:Decoration industry, glass industry;Sign industry;Exhibition industry;Leather textile printing industry, etc.
Printed materials could be:Glass, ceramic tile, ceiling, aluminum sheets, wooden sheets, billboards, acryl sheets, KD board, Plexiglas, foam board & flexible media like wall paper, glistening film, canvas, carpet, leather, paper sheets, etc.
Technical Specification | ||
Item Name |
uv flatbed printer |
|
Model |
uv2030 |
|
Print Technology |
Drop-on-demand Piezo Electric |
|
Working Platform |
Vacuum and automatic height adjustment system |
|
Print-head Type |
Konica 1024-14pl |
|
Print-head No. |
4/5/6/7/8/10/12pcs |
|
Printing Size |
2.0m x 3.0m |
|
RIP Software |
Photoprint 6.1 |
|
Drying System |
UV lamp |
|
Resolution |
360 dpi x 360 dpi 360 dpi x 720 dpi |
|
720 dpi x 360 dpi 720 dpi x 720 dpi | ||
720 dpi x 1440 dpi 1440 dpi x 1440 dpi | ||
Max Printing Speed |
In draft mode up than 120 sq.m/hr |
|
In standard mode up than 80 sq.m/hr | ||
In high resolution mode up than 60 sq.m/hr | ||
Ink |
Ink Type |
UV curing ink |
Ink Color |
4 colors (CMYK); 5 colors (CMYK+W); 6 colors (CMYKLcLm/CMYK+2White)... |
|
|
Printing Materials (120mm thick max.) |
Flat rigid media: glass, ceramic tile, ceiling, aluminum sheets, etc. Flexible media like wall paper, glistening film, canvas, carpet… |
|
Printing Art Life |
Outdoor 5 years, indoor 10 years |
|
Power Supply |
AC220V 50/60HZ 16A |
|
Working Conditions |
Temperature 20-28 degrees, Humidity 40% - 60% |
|
Machine Size |
4.20m*4.17m*1.55m |
|
Printer Weight |
2800kgs |
|
Packing |
by solid wooden crate |
|
