Docan 2510 Wide Format Hybrid Printer

Docan 2510 Wide Format Hybrid Printer thumbnail-1
Docan 2510 Wide Format Hybrid Printer photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Flatbed Printer
Place of Origin:
Shanghai, China
Contact Supplier Request Quote Chat Now
Shanghai Docan Tech Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Plate Type Flatbed Printer
Place of Origin Shanghai, China
Brand Name Docan
Model Number UV2510
Usage Other, hybrid uv flatbed printer Docan 2510
Automatic Grade Automatic
Voltage 220 V
Gross Power 8 Kw
Dimensions(L*W*H) 3.75*2.16*1.33m
Weight 3210 KG
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Docan uv hybrid flatbed printer(2in1) adopts Konica 512-14PL/42PL heads, supporting you high speed with teriffic resolution.

Features of hybrid uv flatbed printer







 1) perfect quality along with competitive Price
We are a manufacturer of hybrid uv flatbed printer and own factory in Shanghai city, China.  We produce China best quality, and support customers with attractive and cometitive price.







2) high speed + high resolution
Konica 512-14PL/42PL head adopted. The printing speed can up to 28 sq.m/h by 8 pass with max 1440 dpi * 1440 dpi of resolution.







3) uv lamp drying System

Uv lamp installed, so that the hybrid uv flatbed printer machine guarantees your printing art dries immediately, so that improves your productivity.







4) more application for clients

Printed media: flat rigid sheets, like glass, ceramic tile, ceiling, aluminum sheets, wooden sheets, billboards, acryl sheets, KD board, Plexiglas, foam board, etc. And flexible banner, such as wall paper, glistening film, canvas, carpet, leather, paper sheets... and materials in roll.



Used in: decoration industry, glass industry, sign industry, exhibition industry, leather textile printing industry, etc.







Specification of Flatbed Printer

General

Info

Model

UV2510

Print Technology

Drop-on-demand Piezo Electric

Printhead Type

JAPAN KM-512-14PL / KM-512-42PL

Printhead No.

4/5/6/7/8/10/12/15/16 pcs

Printhead Controls

Print head temperature & voltage are adjustable by software

Printing Size

2000mm width

Ink Characteristics

UV curing ink

Ink Reservoir

Refillable on the fly while printing/1000ml

Locating Mode

Raster strip/Raster sensor

RIP Software

Photoprint 6.1

Drying System

UV lamp

File Format

TIFF, JPEG, Postscript 3, EPS and PDF

Resolution

360 dpi x 360 dpi      360 dpi x 720 dpi

720 dpi x 360 dpi      720 dpi x 720 dpi

720 dpi x 1440 dpi     1440 dpi x 1440 dpi

Printing Speed

In draft mode up than 28 sq.m ( 4 heads )

In standard mode up than 18 sq.m ( 4 heads )

In high resolution mode up than 11 sq.m ( 4 heads )

Ink

Ink Type

UV curing ink

Ink Color

4 colors (C, M, Y, K) - 7colors (C, M, Y, K, LC, LM + W)

Printing Assistant System

Printing Materials

(1-50mm thickness)

Glass, ceramic tile, ceiling, aluminum sheets, wooden sheets, billboards, acryl sheets, KD board, Plexiglas, foam board & flexible media like wall paper, glistening film, canvas, carpet, leather, paper sheets, etc.

Heating System

Standard (Front heater, Rear heater, Fan)

Color Retains

Outdoor 5 years, indoor 10 years

Color Management

ICC based color, adjustment curves, density adjustment

Printer profile

Power Supply

AC220V  50/60HZ (10%)  16A

Working Conditions

Temperature 20-28 degrees, Humidity 40% - 60%

Dimensions

3.75*2.16*1.33m

Weight

3125 kgs

Packing

Outside packing : Packed by solid wooden carton

Inner packing: sealed with anti-rain & rust plastic bubble film



Shanghai Docan hybrid uv flatbed printers support you good quality and competitive price
