Switching Power Supply ( Profession Manufacturer)

Name: Switching Power Supply ( Profession Manufacturer)
Brand: power-tek
SKU: 111345075
Availability: InStock

US$ 5 - 7 MOQ: 500 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

power-tek

Model Number:

SW-60

Shenzhen Top-Asia Electronics Co., Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

SZ/ HK

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name power-tek

Model Number SW-60

Output Type AC

Connection Desktop

Specifications

1)Ripple & Noise: 80-100mVp-p.
2)Efficiency: 73-95%.
3)Short circuit protection.
4)Overheating Protection.
5)OCP/OVP

Measurement(L×W×H):	*1204732mm*
Product Characteristics:	fixed frequency control circuit, apply to Communicating products, Digital and audio products, Energy-saving and environmental products, Massage equipments, Fitness equipment, Medical equipments and Household appliances.
Safety and Certification:	CCC/CE/UL/FCC/GS/BS/SAA/PSE etc Meet all related safety standard Ultra low no-load/standby power consumption, meet CEC V green power requirements
Output Protection:	Short circuit protection Over voltage protection Over current protection Over temperature protection
Electrical Characteristics:	Input voltage: 100-240VAC (90-264VAC) Input current: 0.7A max. Frequency: 50/60Hz (47-63Hz) Output voltage: 4.6-36V Output current: 0.1-5.0A No-load power consumption: 0.3W max. Efficiency: 80% min. Ripples & noises: 50-180mV Line regulation: ±1% Load regulation: ±5%
Reliability:	Hi-pot test: 3750VAC 60s 5mA max. Insulation resistance: 10M Ω min. Leakage current: 0.25mA max. Operating temperature: 0-40°C Storage humidity: 5-95%RH Burn-in test: Rate Load, 40±5°C, 4 hours EMC standard: EN60950
