Power Supply

Measurement(L×W×H):

82*45*32mm

Product Characteristics:

fixed frequency control circuit, apply to Communicating products, Digital and audio products, Energy-saving and environmental products, Massage equipments, Fitness equipment, Medical equipments and Household appliances.

Safety and Certification:

CCC/CE/UL/FCC/GS/BS/SAA/PSE etc
Meet all related safety standard
Ultra low no-load/standby power consumption, meet CEC V green power requirements

Output Protection:

Short circuit protection
Over voltage protection
Over current protection
Over temperature protection

Electrical Characteristics:

Input voltage: 100-240VAC (90-264VAC)
Input current: 0.7A max.
Frequency: 50/60Hz (47-63Hz)
Output voltage: 4.6-12V
Output current: 0.1-1.0A
No-load power consumption: 0.3W max.
Efficiency: 80% min.
Ripples & noises: 50-180mV
Line regulation: ±1%
Load regulation: ±5%

Reliability:

Hi-pot test: 3750VAC 60s 5mA max.
Insulation resistance: 10M Ω min.
Leakage current: 0.25mA max.
Operating temperature: 0-40°C
Storage humidity: 5-95%RH
Burn-in test: Rate Load, 40±5°C, 4 hours
EMC standard: EN55022 class B/FCC Part 15 class B
EN55024/A1: 2001/EN61000
