Docan UV Glass Door Printing Machine , High Resolution Hybrid Digital Printer FRT3116 With Roll to Roll PartUS$ 40,000 - 140,000MOQ: 1 Set
-
PVC Banner Printing Machine /uv Flatbed Printer on Pvc BannerUS$ 50,000 - 100,000MOQ: 1 Set
Heavy duty chassis ensures holding heavy material up to 450KGS and many years of durability. It can be equipped with Konica512 or Konica1024 or Ricoh GEN5 printhead with built-in temperature sensor and heater, which ensures precise and fluent printing, and less need for cleaning, much UV ink saved every year.
UV flatbed printer with roll-to-roll printing option
High resolution and high-quality piezo electric printhead can achieve excellent production performance and vivid bright colors
4 color printing: YMCK
5 color printing: YMCK+W or YMCK WW
6 color printing: Lc Lm Y M C K
7 color printing: Lc Lm Y M C K W or Lc Lm Y M C K W W
8 color printing: Lc Lm Y M CK W V
Excluding the use of VOC (Volatile Organic Compounds) in the UV curable ink. The ink is environmental friendly and no smell
With advanced Automatic Height Detector which can detect the material thickness and find a good height position for best quality printing
Drawer-type UV lamp cassette makes it easy to replace the UV lamp
Equipped with Japanses THK mute guide rail
Carriage is with a crash sensor with high sensitivity to ensure that the printhead will not be accidentally damaged
The white ink catridge is with the automatic stiring and circulation system, which avoids the clog of the White printhead.
-Easy operation menu. User-friendly
| General Information | |||
| Model | DOCAN FRT3116 | ||
| Catagory | UV Hybrid Printer | ||
| Printing Size | 3.1 x 1.6m; 2.5m x unlimited | ||
| Printing | |||
| Print Technology | drop-on-demand piezo electric inkjet | ||
| Printhead | KM-512MH-14PL/KM-1024MHB-14PL/Ricoh Gen5 7PL | ||
| Printhead Control | Printhead temperature and voltage are adjustable in software | ||
| Ink Type | UV curable Ink | ||
| Ink Reservoir | Refillable on the fly while printing/2000ml | ||
| Rip Software | Photo Print/ONYX/Caldera | ||
| Color Management | ICC based color, curves adjustment, density adjustment | ||
| File Format | Tiff, Jpeg, Pstscript, eps, pdf | ||
| Media Thickness | 1-100mm | ||
| Printhead QTY | KM-512MH-14PL | KM-1024MHB-14PL | Ricoh Gen5 |
| 4-8pcs | 4-16pcs | 4pcs/7pcs | |
| Resolution | KM-512MH-14PL/KM-1024MHB-14PL | Ricoh Gen5 | |
| 720 x 720 dpi | 600 x 600 dpi | ||
| 720 x 1080 dpi | 600 x 900 dpi | ||
| 720 x 1440 dpi | |||
| Printing Speed | KM-1024MHB-14PL | Ricoh Gen5 | |
| 4 pass 28 sqm per hour | 4 pass 40 sqm per hour | ||
| 6 pass 19 sqm per hour | 6 pass 28 sqm per hour | ||
| 8 pass 15 sqm per hour | |||
| Print Colors | 4 colors (CMYK), 6 colors (Lc Lm CMYK), White/Varnish optional | ||
| Drying System | UV Lamp with three power levels | ||
| Medias | |||
| Rigid materials: glass, acrylic, PVC foam board, KT board, Wood, WPC, Metal panels,ceramic tiles, MDF, etc. Flexible materials: Paper, advertising banners, wall paper, Mesh, self-adhesive vinyl |
|||
| Outdoor Life of finished printing | |||
| 3 years (use Docan ink) | |||
| Dimensions and Weight | |||
| Dimensions | 5.13 x 3.16 x 1.44m | ||
| Weight | 2620kg | ||
| Operation | |||
| Power Supply | 50/60Hz 220V(10%)>30A | ||
| Operation Environment | 20°C to 28°C | ||
| Humidity | 40% to 60% | ||
| Warranty | |||
| one year | |||
