Specifications
digital UV flatbed glass printer with konica headfour printhead 4 colors
Effective printing table 1.5m x 2.5m
Digital uv flabed glass printer uv2512
Specification
1) UV four colors Flatbed Printer
2) Konica Minolta printhead
3) 360dpi*360dpi-1440dpi*1440dpi
4) C,M,Y,K or C,M,Y,K,LC,LM + White colors
5) CE Certificate
Perfect Quality Along With Competitive Price
Since we are a few manufacturers of UV flatbed printer in China with many years production experience, we can provide the printer with excellent performance & direct price. You will enjoy our one-stop survice.
Higher Speed Plus Higher Resolution
Konica printhead with 512-14PL/42PL nozzle is used to support you with high speed printing and higher resolution(Max resolution can be up to 1440dpi*1440dpi
Ideal Transmission System
USB optical transmission, interference, to avoid printing garbage.
More Application
Application areas includs:Decoration industry, glass industry;Sign industry;Exhibition industry;Leather textile printing industry, and so on.
Printed materials could be:Glass, ceramic tile, ceiling, aluminum sheets, wooden sheets, billboards, acryl sheets, KD board, Plexiglas, foam board & flexible media like wall paper, glistening film, canvas, carpet, leather, paper sheets, etc.
Technical Data
|
General Info |
Model |
UV2512 |
Print technology |
Drop-on-demand Piezo Electric |
|
Working platform |
Vacuum or up-down wheels table |
|
Printhead type |
JAPAN KM-512-14PL / KM-512-42PL |
|
Printhead No. |
4/5/6/7/8/10/16 pcs |
|
Printhead controls |
Print head temperature & voltage are adjustable by software |
|
Printing size |
1.5m * 2.5m |
|
Ink type |
UV curing ink |
|
Ink Reservoir |
Refillable on the fly while printing/1000ml |
|
Loating mode |
Resto/Servo |
|
RIP software |
Photoprint 6.0 |
|
Drying system |
UV lamp |
|
File format |
TIFF, JPEG, Postscript 3, EPS and PDF |
|
Resolution |
360 dpi x 360 dpi 360 dpi x 720 dpi |
|
720 dpi x 360 dpi 720 dpi x 720 dpi | ||
720 dpi x 1440 dpi 1440 dpi x 1440 dpi | ||
Printing Speed |
In draft mode up than 28 sq.m ( 4 heads ) |
|
In standard mode up than 18 sq.m ( 4 heads ) | ||
In high resolution mode up than 11 sq.m ( 4 heads ) | ||
Ink |
Ink type |
UV curing ink |
Printing colors |
C, M, Y, K, LC, LM, W (4,5,6,7, double 4 colors) |
|
Printing Assistant System |
Printing media (max thickness 55mm ) |
Glass, ceramic tile, ceiling, aluminum sheets, wooden sheets, billboards, acryl sheets, KD board, Plexiglas, foam board, also flexible media like wall paper, glistening film, canvas, carpet, leather, paper sheets, etc. |
Heating system |
Standard (Front heater, Rear heater, Fan) |
|
Color retains |
Outdoor 2 years, indoor 7 years |
|
Color management |
ICC based color, adjustment curves, density adjustment |
|
Printer Info |
Power supply |
AC220V-240V 50/60HZ (10%) 16A |
Working conditions |
Temperature 20-28 degrees, Humidity 40% - 60% |
|
Dimensions |
3.15*1.68*1.33m |
|
Weight |
1000 kgs |
|
Packing |
Outside packing : Packed by solid wooden carton |
|
Inner packing: sealed with anti-rain & rust plastic bubble film | ||
