Specifications
UV Printer1. Printing size: 2.05m*3.2m.
2. Max. printing thickness: 100mm.
3. Print on glass, acrylic, pvc, etc.
UV Printer, uv flatbed printer, flatbed printer
Established in 2005, Shanghai Docan Tech Co.,ltd is a professional UV printer manufacturer. Our machines include UV series and M series. The machines are mainly used in glass industry, craft industry, advertisement industry, leather industry, decoration industry, etc.
Equipment model |
M10 |
Print technology |
Drop-on-demand piezo electric |
Print head type |
Konica KM1024-14PL /42PLhead |
Print head controls |
Print head temperature and voltage are software adjustable |
Ink Characteristics |
UV Curing ink |
Ink Reservoir |
Refillable on the fly while printing/1000ml |
RIP software |
Photoprint 10/Onyx/ Caldera |
Color Management |
ICC based color, adjustment curves, density adjustment |
Drying system |
UV lamp |
File format |
TIFF, JPEG, Postscript3, EPS and PDF |
Power supply |
50/60Hz 220V(20%)>20A |
Operation environment |
Temperature 20°C to 28°C degrees |
Humidity |
40% to 60% |
Product Model |
Docan M10 |
Printing Size |
2.05*3.20m |
Media thickness |
1-100mm |
Print heads Number |
4/5/6/7/8/10/12/14pieces |
|
Resolution |
360dpi*360dpi 360dpi*720dpi |
720dpi*360dpi 720dpi*720dpi | |
720dpi*1440dpi 1440dpi*1440dpi | |
|
Printing speed |
In draft mode up than 60sq.m/h (8 heads) |
In standard mode up than 38 sq.m/h ( 8 heads) | |
In high resolution mode up than 24 sq.m/h (8 heads) | |
Colors |
4 colors(C M Y K) or 6 colors(C M Y K Lc Lm). White & varnish can be optional |
Outdoor life |
2 years(By Docan ink) |
Loating Mode |
Restro/servo |
Dimensions |
4.8*3.93*1.38m |
Packing |
Inner: plastic bubble film sealed anti rain & rust, outside: solid wooden carton packing |
Weight |
2160kg |
