Docan UV 2030 Wide-format Ceiling Printer

Docan UV 2030 Wide-format Ceiling Printer thumbnail-1
Docan UV 2030 Wide-format Ceiling Printer photo-1
US$ 34,750 - 37,730 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Other, no printing plate
Place of Origin:
Shanghai, China
Contact Supplier Request Quote Chat Now
Shanghai Docan Tech Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Port of Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Plate Type Other, no printing plate
Place of Origin Shanghai, China
Brand Name DOCAN
Model Number UV 2030
Usage Other, print image on all kinds of materials
Automatic Grade Automatic
Gross Power 8KW
Dimensions(L*W*H) 4.09X4.17x1.55m

Specifications

1no platemaking,
2 high resolution
3ink dry immediately
4no pollution
5simple operation;6fast printing speed

            The main features and advantages of Docan UV 2030 wide- format ceiling printer

First thanks for your inquiring our UV printers.We are professional manufacturer of UV printers in China.Our company was established in 2005 and now our products have been exported to more than 30 countries such as USA,Brazil,Mexico,Chile,UK,Spain,Finland,Portugal.Italy.Czech,Turkey,Russia,Poland,Ukraine,Monglia,India,Philippines,Indonesia etc.Now I’ll give you a specific introduction on the general features and specification of our UV  printer to make you find more profit modes.



                                Product     feature
1:No platemaking,no pre- and post-process make it very suitable for single piece and small-lot production, sample printing and image effects stimulation.
2:Extensive printed materials:such as glass,ceramic,ceiling,aluminum
sheet, wood board, door sheet, metal panel,billboard,acrylic
panel,plexiglass,paper board, foam board, Chevron board, corrugated
cardboard; flexible materials such as PVC,canvas,cloth,carpet,sticky note, reflective film, leather etc.
3:High-precision,high-speed and long-life Konica
 Minolta  printhead KM512M(14pl)or KM1024MHB.
4:High-performace specialized UV curing ink from Japan Toyo or UK Sunjet has higher color saturation, faster curing,better wear resistance,higher adhesion fastness and no pollutant emission.
5:Excellent ink filter from US PALL,separate air
pressure cleaning system,outside and internal heating system and different flash models prevents printheads from being blocked completely
and gurantee ink jet smoothly.
6:The working table of  aluminum alloy hard anode
oxidation with the flatness with 0.3mm  ensures
color uniformity and has stronger corrosion and wear resistance
7:Vacuum sucking working table makes various printed materials be fixed easily and fast.
8:High speed guide rail with low noise and high
wear resistance from Taiwan HIWIN guarantees the movement stability of X,Y axis.
9:Stable and reliable servo motor from Taiwan Delta or Japan Panasonic provide strong power for
printing
10:High-quality lead screw rod system and grating
scale from Germany JENA ensure the movement of precision
11:Main parts for air and ink circulation are all from Japan SMC,Taiwan TAC and main eletrical parts are from France SCHNEIDER,Germany SIEMENS and Japan OMRON.All these gurantee the stability,reliability and life of the whole machine.
12:Separate and stable negative pressure system for
ink CMYK,W and V ensure no ink fall at unneeded time.
13:Gear switch and shutter equipment for UV lamp to
control UV light intensity make it suitable to different heat resisting materials
14:Effective and reliable crushproof system prevents expensive printheads from being damaged accidently
15:Wide printing size and fitting in with thickest 80mm printed materials expand the appliction areas to the hilt
16:Double-direction printing at X axis double the
printing speed and double-direction feed at Y axis
meet the different sequence demand for printing
CMYK,white and varnish ink.
17:Combining the modern automatic RIP and print
control managenemt software with ingenious
humanized modular design make the operation pretty
simple and easy to learn for just one single operator
18:CE and UL certifications make your business unobstructed through the world
19:Only 8KW power and 24-running make your profit maximize.





                                                Technological Parameter
Product Model Docan UV2030 wide-format ceiling printer
Printhead Technology Drop-on demand piezo electric
Printhead control Printhead temperature and voltage
 are software adjustable
Printhead Type KM512-14PL(kM1024MHB optional)
Printhead Number 4/5/6/7/8/10/12/15/16
Ink Characteristics UV Curing Ink
Ink Type Japan Toyo or UK Sunjet
Ink Reservoir Reliable on the fly while printing/1000ml
Color Control ICC based color,curves and density adjustment
color Type C M Y K or C M Y K Lc Lm +white,varnish optional
Pringting Size 2.0X3.0m
Media Thickness  within 80mm
Printing Resolution
&Speed		 720x720DPI(4pass)          52Sq.m/h(8 KM512 printheads)
720x1080DPI(6pass)        36Sq.m/h(8 KM512 printheads)
720x1440DPI(8pass)        22Sq.m/h(8 KM512 printheads)
1080x1440DPI(12pass)   12Sq.m/h(8 KM512 printheads)
Life of printed image 5 years(outdoor),10year(indoor)
File Format TIFF,JPEG,Postscript,EPS,PDF
RIP Software Photoprint 10
Power Supply 220V 50/60Hz(10%)  more than 20A
Power  <8KW
Operation Enviroment Temperature 20 to 30,Humidity 40% to 60%
Equipment Dimension 4.09X4.17x1.55m
Equipment Weight 1870kg
Warranty 1 year

   In a word, along with the fact that the personalized products are more and more popular, our equipment will provide you more and more profit growth points no matter in providing the equipment or printing service. What’s more, we are searching agent in your country.

 Note:The information above is just for referance and the actual product information is subjected  to the sales contract  confirmation.
