M 10 offset or plate digital media printer

General

Info

Model

M 10

Print Technology

Drop-on-demand Piezo Electric

Printhead Type

JAPAN KM-512-14PL / KM-512-42PL

Printhead No.

4/5/6/7/8/10/12/15/16 pcs

Printhead Controls

Print head temperature & voltage are adjustable by software

Printing Size

2.0m x 3.0m

Ink Characteristics

UV curing ink

Ink Reservoir

Refillable on the fly while printing/1000ml

Loating Mode

Resto/Servo

RIP Software

Photoprint 10

Drying System

UV lamp

File Format

TIFF, JPEG, Postscript 3, EPS and PDF

Resolution

360 dpi x 360 dpi      360 dpi x 720 dpi

720 dpi x 360 dpi      720 dpi x 720 dpi

720 dpi x 1440 dpi     1440 dpi x 1440 dpi

Printing Speed

In draft mode up than 28 sq.m ( 4 heads )

In standard mode up than 18 sq.m ( 4 heads )

In high resolution mode up than 11 sq.m ( 4 heads )

Ink

Ink Type

UV curing ink

Ink Color

4 colors (C, M, Y, K) - 7colors (C, M, Y, K, LC, LM + W)

Printing Assistant System

Printing Materials

(1-50mm thickness)

Glass, ceramic tile, ceiling, aluminum sheets, wooden sheets, billboards, acryl sheets, KD board, Plexiglas, foam board & flexible media like wall paper, glistening film, canvas, carpet, leather, paper sheets, etc.

Heating System

Standard (Front heater, Rear heater, Fan)

Color Retains

Outdoor 2 years, indoor 7 years

Color Management

ICC based color, adjustment curves, density adjustment

Printer profile

Power Supply

AC220V  50/60HZ (10%)  16A

Working Conditions

Temperature 20-28 degrees, Humidity 40% - 60%

Dimensions

4.8 X 3.93 X 1.38 m

Weight

2160 kgs

Packing

Outside packing : Packed by solid wooden carton

Inner packing: sealed with anti-rain & rust plastic bubble film
