Large format digital printing machine

Specifications

Large format digital printing machine
1. temper process;
2.automatic up&down and position;
3. CE Certificate;
4. eco-friend

Large format digital printing machine



Company Profile

Thanks for your inquiring our UV printers!

Shanghai DOCAN technology is professional UV flatbed printer leaders in China .

Established in 2005, now our products have been exported to more than 30 countries, suchas:USA,Brazil,Mexico,Chile,UK,Spain,Finland,Portugal,Italy,Czech,Turke,Russia,Poland,Ukraine,Monglia,India,Philippines,Indonesia etc. Welcome your RFQ so that we can give you a specific introduction to help you find your desired modes.



Application material:

Printed materials could be: glass, ceramic, ceiling, aluminum sheet, wood board, door sheet, metal panel, billboard, acrylic panel, plexiglass, paper board, foam board, PVC expansion board, corrugated cardboard; flexible materials such as PVC, canvas, cloth, carpet, sticky note, reflective film, leather etc.



Application Areas:

Decoration industry, glass industry, sign industry, exhibition industry, rigid paperboard packing industry, leather, textile printing industry, artware industry, furniture industry etc.

Our machine can print material includes rigid sheets, such as glass, metal, acrylic, PVC board, MDF, and the flexible material, like film, leather, canvas, wall paper, ceiling paper etc.

We can provide the printer with excellent performance & competitive price. You will enjoy our one-stop service.



UV ink advantage:

Its instant dry feature that leaves the graphic completely cured. It is not easu to clog the print head

UV ink boasts fewer emissions than solvent inks which is more environmental friendly.





UV Ink Features

Ink Type: It's UV curing ink, environment-friendly ink.

Characteristics: water-proof, anti-uv, heat-resistance.

Printing samples life: 3 years outdoor, and 10 years indoor.

Ink Brand: Belgium AGFA

Can print on flexible material and rigid material



Machine Highlights:



Higher Speed Plus Higher Resolution:
Konica print head with 1024-14PL nozzle is used to support you with high speed printing and higher resolution(Max resolution can be up to 1440dpi*1440dpi)



Double circulation for white color

One small circulation is the circulation within the ink bottle. when the head cartridge stop, the circulation starts. The pump starts to stir the ink bottle.

One big circulation is the circulation from the ink sub tank to the ink bottle

Beside this , there will be automatic frequency flush on the print head set by the software.

In this way, the white clot on the print head can be get rid of .



Solid Mechanical machine structures
The X axial guide rail is imported from JAPAN THK and taiwan PMI . which is more stable than the belt transmission to prevent of the belt will get loose after half years usage. The Y axial we use double screw pole for transmission.



Material Automatic height testing function

The machine can test the material height automatically.



Print head protection system

Print head anti-crash system can protect the print head by stopping the head cartridge in case of print head crash.



All the model we have:

The maximum media thickness can up to 100mm.

The printing size of our machine is

UV2512 2.44*1.22m

UV2510 2.5m width , length is unlimited / roll to roll

M6 2.5*1.2m

M8 2.5*1.8m

M10 2.05*3.2m



Our company contact info:

Tel: +86-15000703327

Skype: chaser_guy

URL :





 Vaccum table, 4-16 Konica print heads, original Toyo UV ink, fast printing and great performance

1. Automatic media thickness checking & printhead carriage height adjustment

2. Automatic printhead wiping mechanism & crash-sensing mechanism for carriage

3. Large, true Flatbed design adapts a strong 6 zones sectional vacuum table to keep media stationary on a flat surface to achieve accurate registration, heavy duty chassis ensures many years durable time. Enabling to hold heavy materials virtually up to 120mm in thickness; black table with high absorbance to reduce UV reflection to eyes.

4.Print directly onto a variety of rigid or sheet-cut flexible materials like vinyl, leather, glass, wood, ceram, acry and more.

5. Advanced and efficient integration Technology UV curable system, provides eco-friendly print condition. One or two UV lambs can be used while printing according to different material for suitable cured result.

6. Negative pressure ink supply system control CMYK colors and white colors separately and built-in temperature sensor & heater type P.H keeps fluent and continuous print, no need automatic nozzle clearing during printing or for standby, lots of UV ink saved every year

7. imaging technology for droplet of 14PL or 42PL,max resolution reaches 1440dpi

8. Basic 4 colors, 6colors white and varnish are available. White options of substrate, cover white, fill white and spot white achieve wonderful white applications.

9. Clear top coating varnish as a separate application is used to increase outdoor life, avoid scratch and add & reduce gloss.



Model:	UV2030
Print Technology:	Drop-on-demand Piezo Electric
Printhead Type:	JAPAN KM512-14PL
Printhead No.:	4/5/6/7/8/10/12/15/16pcs
Printhead Controls:	Print head temperature & voltage are adjustable by software
Printing Size:	205cm x 320cm
Ink Characteristics:	UV curing ink
Ink Reservoir:	Refillable on the fly while printing/1000ml
Loating Mode:	Resto/Servo
RIP Software:	Photoprint10 /ONYX /Caldera
Drying System:	UK Integration uv lamp
File Format:	TIFF, JPEG, Postscript 3, EPS, PDF, and so on.
Resolution:	360 dpi x 360 dpi     360 dpi x 720 dpi
	720 dpi x 360 dpi     720 dpi x 720 dpi
	720 dpi x 1440 dpi     1440 dpi x 1440 dpi
Printing Speed:	In draft mode up than 28 sq.m ( 4 heads )
	In standard mode up than 18 sq.m ( 4 heads )
	In high resolution mode up than 11 sq.m ( 4 heads )
Ink Type:	UV curing ink
Ink Color:	4 colors (C, M, Y, K) - 8 colors (C,M,Y,K,LC,LM+White+Varnish)
Printing Materials:	Glass, ceramic tile, ceiling, aluminum sheets, wooden sheets, billboards, acryl sheets, KD board, Plexiglas, foam board & flexible media like wall paper, glistening film, canvas, carpet, leather, paper sheets, etc.
Heating System:	Standard (Front heater, Rear heater, Fan)
Color Retains:	Outdoor 2 years, indoor 10 years
Color Management:	ICC based color, adjustment curves, density adjustment
Power Supply:	AC220V 50/60HZ (10%) 16A
Working Conditions:	Temperature 20-28 degrees, Humidity 40% - 60%
Dimensions:	4.8m*3.93m*1.38m
Weight:	2160kgs
Packing:	Packed by solid wooden carton.
