Specifications
1no platemaking,no pre-process and post-process2high resolution high speed
4wide size
5high costeffective
3no pollution
The main features and advantages of Docan konica printhead uv wide format industrial inkjet printer
First thanks for your inquiring our UV printers.We are professional manufacturer of UV printers in China.Our company was established in 2005 and now our products have been exported to more than 30 countries such as USA,Brazil,Mexico,Chile,UK,Spain,Finland,Portugal.Italy.Czech,Turkey,Russia,Poland,Ukraine,Monglia,India,Philippines,Indonesia etc.Now I’ll give you a specific introduction on the general features and specification of our UV printer to make you find more profit modes.
10 benefits of our large-fomat UV printer for your Business
1. Print on a far broader range of substrates. Unlike many other printing processes, UV-curing bonds the ink to almost any surface from hand-made canvas and leather to concrete, wood, metal, plastic,ceramic tiles glass,ceiling,aluminum sheet, acrylic paper ,foam ,PVC ,corrugated cardboard,sticky note, reflective film.
2. Wider printed material size:Effective printing size:2.44x1.22m,2.44x1.5m,2.44x1.8m,3.0X2.0m,2.5m+unlimited length Printed material thickness:less than 80mm
3. Open the door to a new world of creative possibilities. The versatility of UV printers offers huge creative potential for your business and clients. Use UV printers for indoor, outdoor and backlit signs, rigid paperboard packing ,leather,textile printing ,artware , decoration, art glass, sign industry, exhibition industry, furniture ,POPs, posters, vehicle wraps, building wraps, cabinets, etc.
4. Say goodbye to pre-treating surfaces,printing plate and coated films or papers. Direct print on printed substrates.Cost of single piece and batch printing is the same,So it’s very suitable for single piece and small-lot production, sample printing and image effects stimulation.
5. Faster drying time means faster production speeds. Unlike water-based and solvent-based ink,UV curing ink can converted to a polymer immediately under the irradiation of UV light.With our UK Primarc UV lamp,the ink drying time is only 0.2s,which translates into high operating speeds
6. Print multiple color layers at the same time. UV flatbed printers keep the media stationary and instead the printhead carriager, which holds the print heads, moves over the media. This together with Stagger printhead arrangement allows for multiple layers of high-speed printing simultaneously including white ink or spot varnishes on highlighted areas of the media
7. Better color saturation on solids and substrates. Advanced color control software and high-performance UV curing ink bring you photo-quality printing effect.
8. Final printed product has higher resistance to fading, rubbing, moisture and heat. Because the ink has been converted to a polymer and already exposed to maximum levels of UV light it’s wonderfully durable and resistant
9. Healthier for your workplace and the planet. Unlike solvent-based inks,UV curing inks haven't volatile organic compounds (VOCs) emitting into the atmosphere,which creates a more pleasant and safer work environment for your staff.
10. You’ll even save on your electricity bill. Conventional large-format printers use heat to cure the ink and consume a large amount of power to create this heat,while our UV printers use either mercury/quartz or LED lights for curing, rather than heat.Our high-performance and long-life UV lamp from UK Primarc has the higher level of curing efficiency and at least1000-hour life.The total power of the printer is less than 8KW.
| Specification | |
| Product Model | Docan UV2512/2518/2030/M8/2510 |
| Printhead Technology | Drop-on demand piezo electric |
| Printhead control | Printhead temperature and voltage are software adjustable |
| Printhead Type | Konica KM512-14PL(Konica KM1024MHB optional) |
| Printhead Number | 4/5/6/7/8/10/12/14/15/16 |
| color Type | CMYK(Lc,Lm,W optional) |
| Pringting Size | UV2512:2.44X1.22m UV2030:3.0X2.0m UV2518:2.44X1.8m UV M8 :2.44X1.5m UV2510:2.5m+unlimited length |
| Media Thickness | less than 80mm(UV2510 less than 60mm) |
| Printing Resolution &Speed(an array KM512-14pl printhead) |
720x720DPI(4pass) 42Sq.m/h 720x1080DPI(6pass) 28Sq.m/h 720x1440DPI(8pass) 22Sq.m/h 1080x1440DPI(12pass) 12Sq.m/h |
| Life of printed image | 5 years(outdoor),10year(indoor) |
| File Format | TIFF,JPEG,Postscript,EPS,PDF |
| RIP Software | Photoprint 10(Caldra optional) |
| Power Supply | 220V 50/60Hz(10%) |
| Power | less than 8KW |
| Operation Enviroment | Temperature 20 to 30,Humidity 40% to 60% |
| Equipment Dimension | UV2512:4.52(L)X2.05(W)X1.33(H)m UV2030:4.09(L)X4.17(W)X1.55(H)m UV2518:4.52(L)X2.46(W)X1.33(H)m UV M8 :4.63(L)X2.48(W)X1.47(H)m UV2510:4.89(L)x2.89(W)x1.81(H)m |
| Equipment Weight | UV2512:1050kg UV2030:1870kg UV2518:1300kg UV M8 :1870kg UV2510:3125kg |
| Certification | CE&UL |
| Warranty | 1 year exclude the Print head |
| After-sale Service | Free installtion,debugging and training 24-hour on-line realtime technology service |
Guarantee and after-sale service:
We have one-year warranty for the whole machine exclude the printhead(because you know it has the brand quality guarantee and we also haven’t warranty from Japan Konica company).
We’ll provide free installation,debugging, training and 24-hour realtime online technology support.
Payment terms: 30%T/T IN ADVANCE, 70% AGAINST COPY OF B/L
Shipping terms: within 20 working days after receiving 30% deposit.Shipping Port:Port of Shanghai
Docan large-format UV digital printer for sheet & coil material(UV2510)
