Specifications
Shanghai Docan flatbed printer adopts1. Konica 512-14PL/42PL heads,
2. supporting you high speed with terrific resolution.
The Latest UV flatbed printer Price, surprising affordable Large format UV Printer, Docan uv flatbed printer uv 2030
Features of flatbed printer
1) perfect quality along with competitive Price
We are a manufacturer of uv flatbed printer and own factory in Shanghai city, China. We produce China best quality, and support customers with attractive and cometitive price.
2) high speed + high resolution
Konica 512-14PL/42PL head adopted. The printing speed can up to 28 sq.m/h by 8 pass with max 1440 dpi * 1440 dpi of resolution.
3) uv lamp drying System
Uv lamp installed, so that the flatbed printer machine guarantees your printing art dries immediately, so that improves your productivity.
4) more application for clients
Printed media: flat rigid material, like glass, ceramic tile, ceiling, aluminum sheets, wooden sheets, billboards, acryl sheets, KD board, Plexiglas, foam board, etc. And flexible media, such as wall paper, glistening film, canvas, carpet, leather, paper sheets...
Used in: decoration industry, glass industry, sign industry, exhibition industry, leather textile printing industry, etc.
Technical Data of Flatbed Printer | ||
|
General Info |
Model |
UV2030 |
Print Technology |
Drop-on-demand Piezo Electric |
|
Printhead Type |
JAPAN KM-512-14PL / KM-1024-14PL |
|
Printhead No. |
4/5/6/7/8/10/12/15/16 pcs |
|
Printhead Controls |
Print head temperature & voltage are adjustable by software |
|
Printing Size |
2.0m x 3.0m |
|
Ink Characteristics |
UV curing ink |
|
Ink Reservoir |
Refillable on the fly while printing/1000ml |
|
Locating Mode |
Raster strip/Raster sensor |
|
RIP Software |
Photoprint 10 |
|
Drying System |
UV lamp |
|
File Format |
TIFF, JPEG, Postscript 3, EPS and PDF |
|
Resolution |
360 dpi x 360 dpi 360 dpi x 720 dpi |
|
720 dpi x 360 dpi 720 dpi x 720 dpi | ||
720 dpi x 1440 dpi 1440 dpi x 1440 dpi | ||
Printing Speed |
In draft mode up than 28 sq.m ( 4 heads ) |
|
In standard mode up than 18 sq.m ( 4 heads ) | ||
In high resolution mode up than 11 sq.m ( 4 heads ) | ||
Ink |
Ink Type |
UV curing ink |
Ink Color |
4 colors (C, M, Y, K) - 7colors (C, M, Y, K, LC, LM + W) |
|
Printing Assistant System |
Printing Materials (1-50mm thickness) |
Glass, ceramic tile, ceiling, aluminum sheets, wooden sheets, billboards, acryl sheets, KD board, Plexiglas, foam board & flexible media like wall paper, glistening film, canvas, carpet, leather, paper sheets, etc. |
Heating System |
Standard (Front heater, Rear heater, Fan) |
|
Color Retains |
Outdoor 5 years, indoor 10 years |
|
Color Management |
ICC based color, adjustment curves, density adjustment |
|
Printer profile |
Power Supply |
AC220V 50/60HZ (10%) 16A |
Working Conditions |
Temperature 20-28 degrees, Humidity 40% - 60% |
|
Dimensions |
4.09*4.17*1.55m |
|
Weight |
1780 kgs |
|
Packing |
Outside packing : Packed by solid wooden carton |
|
Inner packing: sealed with anti-rain & rust plastic bubble film | ||
