Specifications
UV flatbed printer docan1. no platemaking, high resolution
2. ink dry immediately, simple operating
3.fast printing
UV flatbed printer docan
Application material:
Printed materials could be: glass, ceramic, ceiling, aluminum sheet, wood board, door sheet, metal panel, billboard, acrylic panel, plexiglass, paper board, foam board, PVC expansion board, corrugated cardboard; flexible materials such as PVC, canvas, cloth, carpet, sticky note, reflective film, leather etc.
Application Areas:
Decoration industry, glass industry, sign industry, exhibition industry, rigid paperboard packing industry, leather, textile printing industry, artware industry, furniture industry etc.
Our machine can print material includes rigid sheets, such as glass, metal, acrylic, PVC board, MDF, and the flexible material, like film, leather, canvas, wall paper, ceiling paper etc.
Specification |
|
Model: |
M6 |
Print Technology: |
Drop-on-demand Piezo Electric |
Printhead Type: |
JAPAN KM1024MHB-14PL |
Printhead No.: |
CMYK+LC+LM+WHITE(7Printhead) |
Printhead Controls: |
Print head temperature & voltage are adjustable by software |
Printing Size: |
250cm x 122cm |
Ink Characteristics: |
UV curing ink |
Ink Reservoir: |
Refillable on the fly while printing/1000ml |
Loating Mode: |
Resto/Servo |
RIP Software: |
Photoprint10 |
File Format: |
TIFF, JPEG, Postscript 3, EPS, PDF, and so on. |
|
Resolution:
|
360 dpi x 360 dpi 360 dpi x 720 dpi |
720 dpi x 360 dpi 720 dpi x 720 dpi | |
720 dpi x 1440 dpi 1440 dpi x 1440 dpi | |
|
Printing Speed:
|
In draft mode up than 58sq.m |
In standard mode up than 30sq.m | |
In high resolution mode up than 15sq.m | |
Ink Type: |
UV curing ink |
Ink Color: |
CMYK+LC+LM+WHITE(7colors) |
Printing Materials: |
Glass, ceramic tile, ceiling, aluminum sheets, wooden sheets, billboards, acryl sheets, KD board, Plexiglas, foam board & flexible media like wall paper, glistening film, canvas, carpet, leather, paper sheets, etc. |
Heating System: |
Standard (Front heater, Rear heater, Fan) |
Color Retains: |
Outdoor 2 years, indoor 10 years |
Color Management: |
ICC based color, adjustment curves, density adjustment |
Power Supply: |
AC220V 50/60HZ (10%) 16A |
Working Conditions: |
Temperature 20-28 degrees, Humidity 40% - 60% |
Dimensions: |
4.65m*2.2m*1.58m |
Weight: |
1580kgs |
Packing: |
Packed by solid wooden carton. |
Media thickness |
1-100mm |
Printing speed |
4 pass: 30 sq.m/h (4 heads) |
6 pass: 20 sq.m/h (4 heads) | |
8 pass: 14 sq.m/h (4 heads) | |
Trade terms: |
FOB Shanghai |
payment terms |
T/T30%deposit,70%balance before shipment |
The uv flatbed printer delivery time and warranty,install and training.
1. The uv flatbed printer delivery time is 7 working days after received the deposit payment.
2. The uv flatbed printer warranty is 1 year,except the printhead, ink filter,ink pump was not in warranty.
3. The install we can send technical engineer to customer workshop to install the uv printer.
4. The training and the install at the same time,it can be finished in 4 days.
All the model we have:
1. The maximum media thickness can up to 100mm.
The printing size of our machine is
UV2512 2.44*1.22m
UV2510 2.5m width , length is unlimited / roll to roll
M6 2.5*1.2m
M8 2.5*1.8m
M10 2.05*3.2m
2. UV ink from UK sunjet or Japan Toyo ink (import ink and environment protection)
3. Motor server & electricity use Japan Panasonic
4. UV lamp from UK PRIMAC. use uv light cure uv ink printing on material surface.
5. Vacuum or up-down wheel tables
6. Printing size have 2 x 3m and 2.5 x 1.8m ,1.5m x 2.5m
7. Print heads number from 4 to 16 heads
8. Max printing speed is 60sq.m/h(16 heads)
9. Printing colors, C M Y K 4 colors or C M Y K LC LM 6 colors, additional have white color
10. Printing material thickness is up to 5 cm.
11. the printing material can be as glass,aluminum,acrylic,metal, MDF,wood,pvc ,leather,tile,etc all sheet material
12. the printing life span, for indoor 10 years. for outdoor 5 years warranty.
13. RIP software ,we use the updated photoprint 6.0 ,usb dongle.
14. printer control software is docan printer control software,developed by docan company.
have English and Chinese two version.
15. Printing picture format requirements, TIFF, JPEG,Postscript 3,EPS and PDF
16. Printing colors controls,ICC based colors, adjustment curves,density adjustment,
17. Printing resolutions, 360 dpi x 360 dpi, 360 dpi x 720 dpi,720dpi x 360 dpi, 720 dpi x 720 dpi, 720 dpi x 1440 dpi, 1440 dpi x 1440 dpi.
18. Printing speed example for 4 heads 4 color( C M Y K ) speed,
In draft mode up than 28 sq.m /hour , In standard mode higher than 18 sq.m/hour
In high resolution mode up than 11 sq.m/hour , In super resolution mode is 6 sq.m/hour
19. For printing 1 sq.m with 4 color full printing the ink consume is 10 ml, the price of ink for 1 sq.m is $1/sq.m
