UV Printer

UV Printer thumbnail-1
UV Printer thumbnail-2
UV Printer thumbnail-3
UV Printer photo-1
UV Printer photo-2
UV Printer photo-3
US$ 52,000 - 68,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Flatbed Printer
Place of Origin:
China
Contact Supplier Request Quote Chat Now
Shanghai Docan Tech Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Plate Type Flatbed Printer
Place of Origin China
Brand Name Docan
Model Number M10
Usage Bill Printer, Card Printer
Automatic Grade Automatic

Specifications

1)The leading UV printer manufacturer;
2)The best selling model in the market;
3)The most competitive price and prompt service

Docan M10 UV Flatbed printer
M10 UV Flatbed Printer is a kind of large inkjet printer mainly used to print images on flatbed material,  The images designed on the computer can be printed out as their original shape
The maximum printing size of this flatbed printer is 2.05m x 3.20m

Features of Docan M10
Our M10 UV flatbed printer can print images on all kinds of flatbed materials. Such as glass, acrylic, PVC foam board,  ceramic, aluminum composited panel, corrugated board, aluminum sheet, metal,wave board, wood , MDF,ceiling, wall paper, corrugated paper,timely paste,canvas, leather,etc.
Special treatment to flatbed materials is unnecessary.
The maximum printing material thickness is 80mm.
The printing effect is very good and the images are firmly printed on the panels, This ensures that the printing effect can be well preserved for a long time without fading(indoor for 10 years and outdoor for 3 years.)

Basic Characteristics of M10
Model M10
Catagory  M series
Print Technology Drop-on-demand Piezo Electic
Nozzle Technology Piezoelectric Inkjet
Print head type KM-1024-14PL
Print head controls Print head temperature and voltage are software adjustable
Ink Characteristics UV curing ink
Ink Reservoir Refillable on the fly while printing/ 1000ml
Drying system UV lamp
Rip software Photoprint/ Onyx/ Caldrea
Color Management Icc Based Color, Curves Adjustment, Density Adjustment
File Format Tiff, Jpeg, Postscript 3, Eps and Pdf
Power supply 50/60hz 220v ( 10%) >30A
Operation Environment  Temperature 20°C  to 28°C degrees
Humidity 40% to 60%
Product Model Docan M10
Printing Size 205*3.2m
Media thickness 1-100mm
Nozzle Number 4/5/6/7/8/10/12/15/16pcs
Resolution 360dpi*360dpi  360dpi*720dpi
720dpi*360dpi  720dpi*720dpi
720dpi*1440dpi 1440dpi*1440dpi
Printing speed In Draft mode up than 58 sq.m/h (8 heads)
In Standard mode up than 42 sq.m/h ( 8 heads)
In High resolution mode up than 34 sq.m/h (8 heads)
In Super resolution mode up than 26 sq.m/h ( 8 heads)
Colors 4 colors(C M Y K) or 6 colors(C M Y K Lc Lm). White & varnish can be optional
Outdoor life 2 years(use Docan ink)
Dimensions  4.8*3.93*1.38m
Weight 2160KG
