Specifications
1)speed:12-14bpm2)automatic
3)CE compliant
4)MOQ:1set
Applications:
Shrink wrapping machine is mainly used for the industry packages for beverage, foods ,no foods glass, plastic bottles and cans, etc.
Function:
The machine can automatic finish bottle in-feeding, bottle formation, convey bottle, feed film to wrap and hot shrink to finish package.
Characteristics:
1) PLC control, English and Man-machine interface, operating easy and simple maintain
2) Feeding film is tracked by photoelectrical sensor to ensure the accuracy film length.
3) Advanced inverter to control speed and rotary air circulation structure.
4) Heating channel employs three layers heating proof material, in case heating energy wasting, save the power and cost.
5) Fast cooling channel to keep the output product elegance appearance ,reduce breakdown ration and easy to transfer
Parameter:
- Model: 100A
- Weight: 1500kg
- Thermal shrink passage size :L1800*W650*H450
- Max. size of the package: L600*W400*H350
- Packing speed :12-14 bags/min
- Width of the convey belt :600MM
- Power supply: 380V, 3phase, 18KW
- Air pressure: 0.6-0.8Mpa
- Air consumption: 0.6m3/min
