Help CenterGranular Beverage 4 in 1 Filling Machine DGF 24-24-24-8
Related Products
-
Carbonated Filling MachineNegotiableMOQ: 1 Unit -
DGF32-32-10 Bottled Liquid Filling MachineNegotiableMOQ: 1 Set
-
DGF 24-24-8 Three in One Cabonated Water Filling MachineNegotiableMOQ: 1 Set
-
DGF 18-18-6 Soft Drink Filling MachineryNegotiableMOQ: 1 Set
-
3-in-1 Carbonated Liquid Filling MachineNegotiableMOQ: 1 Set
Specifications
1. Product: carbonated water, CSD, soft drink2. Capacity: 3000 - 50000BPH(@500ml)
3. Authentication: ISO, CE, UL, SGS, FDA
Filling machine
Rinsing rinsing filling sealing 4 in 1 soft drink filling machine
Washer filler capper carbonated water filler
Filling Line Process Flow:
- Water treatment system
- Sugar melting system
- Blending system
- Injection molding machine / blow molding machine
- Unscrambler
- Air conveyor
- Rinsing-filling-capping 3 in 1 monoblock
- Warming tunnel, air dryer
- Lamp inspector, sleeve labeling system
- Ink jet printer
- Shrink wrapper / wrap-round case packer
- CIP system
- Etc.
Main components:
1) PLC: Omron (Japan)
2) Touch screen: Weinview (Taiwan)
3) Transducer: Omron (Japan)
4) Electric parts: Schneider (French)
5) AC contactor: Schneider
6) Power switch: Schneider
8) Cylinder: Airtac (Taiwan)
Technical Specifications (@500ml):
Model |
DGF12-12-6 |
DGF18-18-6 |
DGF24-24-8 |
DGF32-32-8 |
DGF40-40-10 |
Capacity (b/h) |
3000-4000 |
4000-6000 |
8000-10000 |
10000-14000 |
12000-15000 |
Filling precision |
≤± 5mm (Liquid Level) |
||||
Suitable bottle specification (mm) |
φ50-φ100;(Height):170-320 |
||||
suitable cap Shape |
Plastic Screw Cap |
||||
Total power (kw) |
2.2 |
3 |
4.8 |
5.7 |
7.5 |
weight (kg) |
2600 |
3500 |
4800 |
6500 |
10000 |
Overall dimensions(mm) |
2300*1680*2650 |
2500x1760x2650 |
3100x2100x2650 |
3800x2800x2650 |
4000x3300x3400 |
Worldsfilling product catalog:
1. Water treatment system
2. Purified & mineral water filling production line
3. Fruit & tea juice filling production line
4. Carbonated beverage filling production line
5. Oil filling production line
6. Can beverage filling production line
7. Bottle packing system
8. Other auxiliary equipments
Which product do u wanna buy? Bottle size? Product capacity? Tell us pls, our engineer will serve u.
