Specifications
Mini laser module for Mini laser star holographic laser star projectorcustomized design
reliability and stability up to 98%
Mini laser module for Mini laser star holographic laser star projector
Key Feature
1. High quality
2. High Stability
3. High reliability
4. APC driving circuit
5. Low cost
6. Long Life
Application:
- Industrial Instruments and Equipments
- Wild Explore Instruments
- Military Instruments and Equipments
- Medical Instruments
- Surveying Instruments
- Bar Scan
Items |
Specifications |
||||||||
Spectral Range |
Violet |
Blue |
Red |
Infrared |
|||||
Wavelength |
405nm |
450nm |
635nm |
650nm |
780nm |
808nm |
830nm |
850nm |
980nm |
LD power(mW) |
5- 50 |
5-60 |
5~180 |
5~150 |
5~200 |
50~5000 |
5-100 |
5~100 |
20~5000 |
Operating Current |
25~5000mA |
||||||||
Input Voltage |
2.6~5.5VDC |
||||||||
Operating Temp. |
-10°C ~ 50°C |
||||||||
Storage Temp. |
-40°C ~ 80°C |
||||||||
Power Stability |
> 98% (@2.7 ~ 5.5VDC) |
||||||||
> 95% (@-10°C ~ 50°C) | |||||||||
MTTF |
>10000 Hrs. |
||||||||
Circuit Protection |
Static, Surge, and Reverse Polarity Protected |
||||||||
Case Material |
Brass or Aluminum |
||||||||
Beam Pattern |
Dot, Line ,Cross |
||||||||
Note:
1, The Dot series laser diode module is customized product with different plastic and glass lens. Thus the
laser shape could be an ellipse or circle with various divergence, beam size and aperture. The output
power is adjustable according to customers’ requirements.
2, Dimensions are customized according to customer’s needs except the ones listed.
3, More models could be offered such as EL65D05IGX, EL65D05IG6,EL65D05IG7,EL65D05IG10,
EL65D05IG15, etc. Elite is continually developing new models and launching to me.
QC Flow
1 Professional Power Meter for double check
2 Qualified professional staff for the beam size/line thickness testing
3 Strictly surface Inspection before load to the warehouse.
Sent Us Inquiry Now and Pls mention the following points:
1 Wavelength
2 Output Powder
3 Housing Dimension
4 Work distance
5 Beam size/Line thicknes
Send Inquiry to This Supplier
