Green Laser Diode Module (5*10mm) With MINI Size

Green Laser Diode Module (5*10mm) With MINI Size thumbnail-1
Green Laser Diode Module (5*10mm) With MINI Size photo-1
US$ 5 - 56 MOQ: 5 Pieces
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
ELITE
Model Number:
VB520D05VG1
Contact Supplier Request Quote Chat Now
Elite Optoelectronics Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
China Maid Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin China
Brand Name ELITE
Model Number VB520D05VG1
Type Laser Diode
Package Type Other, Other, :As customer request

Want to know more Produces details Pls contact us .

Green Laser Diode Module (5*10mm) with MINI Size

Specification

-compact size
-FDA ISO2000:2008
-SGS TUV assessed supplier
-wide work temperature
-high reliability

Compact Size Mini Green Laser Diode Module (4*9mm)



Direct Diode Green Laser, Not DPSS!!



Less Power Consumption, Higher reliability and Stability, Better Effectivity!!



Compact Mini Size, More Applications!!! For small Gadgets!!! Revolution Product



Features



Wavelength:520 nm

High brightness, optical output power: <5.0 mW

Low operating current: <180mA

Low operating voltage: 3VDC

Class IIIa laser, CDRH/ROHS compatible

Static, Surge, and Reverse Polarity Protected

Circuit control: Auto power control (APC)

Operating Temperature: -10 to 50°C



 Optical and Electrical Characteristics



Parameter

Specifications.

Test Conditions

Wavelength

520 nm

Tc = 25°C

Output Power

4 ± 0.8mw

Tc = 25°C

Laser Modes

CW



Transverse mode

TEM00



Output Aperture

< 1.5 mm

Factory fixed

Beam Size

< 8 mm

Factory fixed @ 10m

Divergence

< 0.8 mrad

Tc = 25 ±3°C

Stability

> 80 %



Operating Current

< 180 mA

Tc = 25±3°C

Operating Voltage

3 VDC



Operating Temp.

0°C ~ 45°C



Storage Temp.

-20°C ~ 70°C



Optics

Glass Lens



CDRH Class

Class IIIa



MTTF

8000 Hrs.

Tc = 25±3°C

Green Laser Diode Module (5*10mm) with MINI Size

Green Laser Diode Module (5*10mm) with MINI Size

Green Laser Diode Module (5*10mm) with MINI Size
