Industrial 830nm Laser Module

Industrial 830nm Laser Module thumbnail-1
Industrial 830nm Laser Module photo-1
US$ 3 - 90 MOQ: 5 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Shaanxi, China
Brand Name:
Elite
Model Number:
VB520D05VG1
Contact Supplier Request Quote Chat Now
Elite Optoelectronics Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Xi`An
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shaanxi, China
Brand Name Elite
Model Number VB520D05VG1
Type Laser Diode

Specifications

-Customized product
-FDA ISO2000:2008
-SGS TUV assessed supplier
-Wide work temperature
-High reliability

Elite Optoelectronics Co., LTD,  have many types of dot laser diode module for different application. The light spot can e ellipse and round shaped with varied beam size, aperture and divergence. The difference depends on the glass lens or plastic lens. Customers can chose different types according to their specific applications.

Note:

1) The Dot laser module has different kinds of lens available for different application. We still have more models like ELxxDxxIG4, ELxxDxxIG5, and ELxxDxxIG10 and so on.

2) Elite Optoelectronics also could offer more kinds of mechanical dimension by customers’ requirements

3) Dot laser module still have more wavelength, such as 405nm 480nm 780nm 808nm 850nm 980nm.



Key Feature

1. High quality

2. High Stability

3. High reliability

4. APC driving circuit

5. Low cost

6. Long Life



Application:

1. Industrial Instruments and Equipments

2. Wild Explore Instruments

3. Military Instruments and Equipments

4. Medical Instruments

5. Surveying Instruments

6. Bar Scan





Items

                           Specifications

Spectral Range

Violet

Blue

Red

Infrared

Wavelength

405nm

450nm

635nm

650nm

780nm

808nm

830nm

850nm

980nm

LD power(mW)

5- 50

5-60

5~180

5~150

5~200

50~5000

5-100

5~100

20~5000

Operating Current

25~5000mA

Input Voltage

2.6~5.5VDC

Operating Temp.

-10°C ~ 50°C

Storage Temp.

-40°C ~ 80°C

Power Stability

> 98% (@2.7 ~ 5.5VDC)

> 95% (@-10°C ~ 50°C)

MTTF

>10000 Hrs.

Circuit Protection

Static, Surge, and Reverse Polarity Protected

Case Material

Brass or Aluminum

Beam Pattern

Dot, Line ,Cross



Notes:

1) Part of the laser module could be worked at 60-70°C

2) Power Stability was defined as the power output shift at the operating voltage or temperature changing process

3) Operating Voltage also could be 9 ~12VDC

4) High power output red laser module have 110VAC or 220VAC power adapter





Laser Module-

1, High quality industrial laser diode

2, APC driving circuit

3, Low cost

4, High reliability

5, Long life



 Industrial 830nm laser module



Industrial 830nm laser module

 Industrial 830nm laser module
