405nm Blue Laser Pointer 200mW

405nm Blue Laser Pointer 200mW thumbnail-1
405nm Blue Laser Pointer 200mW thumbnail-2
405nm Blue Laser Pointer 200mW thumbnail-3
405nm Blue Laser Pointer 200mW thumbnail-4
405nm Blue Laser Pointer 200mW photo-1
405nm Blue Laser Pointer 200mW photo-2
405nm Blue Laser Pointer 200mW photo-3
405nm Blue Laser Pointer 200mW photo-4
US$ 50 - 200 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Shaanxi, China
Brand Name:
ELITE
Model Number:
405nm Laser Module
Contact Supplier Request Quote Chat Now
Elite Optoelectronics Co., Ltd.
Gold Verified Supplier
6Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Xi'an Shaanxi China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shaanxi, China
Brand Name ELITE
Model Number 405nm Laser Module

Laser Module, 405nm Violet Line Laser Module, 5mW-120mW 405nm Laser Diode Module Dot & Line Beam with Built-in PD

1.Elite 405nm Laser Diode Module Description:

Elite could provide high quality 405nm (Violet) 5mw-120mw Dot & Line laser diode module. Except the models listed below, several more options are available. Elite could also do customized new Blue Violet & Green Laser Diode Module.



2.Elite 405nm Laser Diode ModuleFeatures:
a. High stability and high reliability

b. Compact size

c. Low power consumption

d. Customized solutions for OEM applications



3.Elite 405nm Laser Diode Module (Dot Beam)Specifications:

Model

Wave

Length

Output Power

Driver

Aperture

Divergence

Beam Size

Dimension

VB405D05VG1

405nm

<2.5mW

APC

Dia.4.5mm

0.2mrad

Dia.5mm@10m

Dia.10x35mm

VB405D05VG2

405nm

<3.5mW

APC

Dia.5.0mm

0.2mrad

4x8mm@10m

Dia.12x40mm

VB405D05VG3

405nm

<3.0mW

APC

Dia.6.0mm

0.1mrad

Dia.6mm@20m

Dia.14x50mm

VB405D10VG1

405nm

<5.0mW

APC

Dia.4.5mm

0.1mrad

Dia.5mm@10m

Dia.10x35mm

VB405D10VG2

405nm

<7.0mW

APC

Dia.5.0mm

0.2mrad

4x8mm@10m

Dia.12x40mm

VB405D10VG3

405nm

<6.0mW

APC

Dia.6.0mm

0.1mrad

Dia.6mm@20m

Dia.14x50mm

VB405D20VG1

405nm

<10.0mW

APC

Dia.4.5mm

0.1mrad

Dia.8mm@20m

Dia.12x40mm

VB405D20VG2

405nm

<14.0mW

APC

Dia.5.0mm

0.2mrad

6x12mm@20m

Dia.12x40mm

VB405D20VG3

405nm

<10.0mW

APC

Dia.6.0mm

0.1mrad

Dia.6mm@20m

Dia.14x50mm

VB405D40VG1

405nm

<20.0mW

APC

Dia.4.5mm

0.1mrad

Dia.8mm@20m

Dia.14x50mm

VB405D40VG2

405nm

<28.0mW

APC

Dia.5.0mm

0.2mrad

6x12mm@20m

Dia.14x50mm

VB405D40VG3

405nm

<20.0mW

APC

Dia.6.0mm

0.1mrad

Dia.6mm@20m

Dia.14x50mm

VB405D60VG1

405nm

<30.0mW

APC

Dia.4.5mm

0.1mrad

Dia.8mm@20m

Dia.14x50mm

VB405D60VG2

405nm

<40.0mW

APC

Dia.5.0mm

0.2mrad

6x12mm@20m

Dia.14x50mm

VB405D60VG3

405nm

<40.0mW

APC

Dia.6.0mm

0.1mrad

Dia.6mm@20m

Dia.14x50mm

VB405D100VG1

405nm

<50.0mW

APC

Dia.4.5mm

0.1mrad

Dia.8mm@20m

Dia.16x60mm

VB405D100VG2

405nm

<70.0mW

APC

Dia.5.0mm

0.2mrad

6x12mm@20m

Dia.16x60mm

VB405D100VG3

405nm

<60.0mW

APC

Dia.6.0mm

0.1mrad

Dia.6mm@20m

Dia.14x50mm



4. Elite 405nm Laser Diode ModuleApplications:

a. Laser alignment and positioning

b. Industrial instruments and equipments

c. Medical Treatment Instruments

d. Other OEM applications……



5. Why Choose us?

12 years rich industry experience since 2003

SGS TUV assessed supplier

Have FDA, ISO9001:2008, IEC certificates

Cooperation with Top 500 Global Companies like GE, Corning etc.



6. Packaging & Delivery & Payment Information:

MOQ: 10pcs.

Supply Ability: 100,000pcs per month.

Delivery Time: 10-20 days depending on order quantity.

Shipment Term: FOB Xi’an, China.

Payment Terms: T/T, Western Union, Paypal

Shipping Method: DHL/EMS/TNT Air-Express or sea transportation.



7.Warranty:

We offer 12 months limited warranty for our products. Damage due to misuse, ill treatment and unauthorized modifications and repairs are not covered by our warranty.



8.CAUTION:

The laser light is harmful to human body especially to eye no matter what directly or indirectly. The laser beam shall be observed or adjusted through infrared camera or equivalent.



9.Elite Factory:

405nm Blue Laser Pointer 200mW



10.Elite Production Process:

405nm Blue Laser Pointer 200mW



11.Meet us on Exhibitions:

a.Shot Show Exhibition held in USA in January.

b.Laser World of PHOTONICS held in Germany in June.

c.Laser World of PHOTONICS held in China in March.

405nm Blue Laser Pointer 200mW
