Help CenterCompact (4*9mm) Laser Diode Module
Related Products
-
Compact Mini Green Laser Diode ModuleUS$ 5 - 56MOQ: 5 Pieces -
520nm 1 mw Green Laser Module With Compact SizeNegotiableMOQ: 10 Pieces
-
Compact Size 520nm 1 mw Green Laser ModuleNegotiableMOQ: 10 Pieces
-
High Stability Laser Module 1W TEC Control Power LaserUS$ 5 - 130MOQ: 100 Pieces
-
High Reliable 520nm 1 mw Green Laser Module Wide Work TemperatureNegotiableMOQ: 10 Pieces
Specifications
11 years experienceFDA IEC SGS ISO9001-2008
Wide temperature range -10C ~ 50C
green laser
High Reliable
Product details:
Wavelength:520 nm
High brightness, optical output power: <5.0 mW
Low operating current: <180mA
Low operating voltage: 3VDC
Class IIIa laser, CDRH/ROHS compatible
Static, Surge, and Reverse Polarity Protected
Circuit control: Auto power control (APC)
Operating Temperature: -10 to 50°C
Optical and Electrical Characteristics
Parameter |
Specifications. |
Test Conditions |
Wavelength |
520 nm |
Tc = 25°C |
Output Power |
4 ± 0.8mw |
Tc = 25°C |
Laser Modes |
CW |
|
Transverse mode |
TEM00 |
|
Output Aperture |
< 1.5 mm |
Factory fixed |
Beam Size |
< 8 mm |
Factory fixed @ 10m |
Divergence |
< 0.8 mrad |
Tc = 25 ±3°C |
Stability |
> 80 % |
|
Operating Current |
< 180 mA |
Tc = 25±3°C |
Operating Voltage |
3 VDC |
|
Operating Temp. |
0°C ~ 45°C |
|
Storage Temp. |
-20°C ~ 70°C |
|
Optics |
Glass Lens |
|
CDRH Class |
Class IIIa |
|
MTTF |
8000 Hrs. |
Tc = 25±3°C |
Processing contol plan being followed strickly,
and the passed Certifications could be found below:
Customer Concerns:
The Coming Trade Shows which we`ll attend in,
Services Cycle:
laser beam expander
