C BAND Satellite Antenna

Name: C BAND Satellite Antenna
Brand: FURUI
SKU: 111269693
Availability: InStock

US$ 4 - 10 MOQ: 500 Sets

Key Specifications

Place of Origin:

Hebei, China

Brand Name:

FURUI

Model Number:

C BAND

Renqiu Furui Communication Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

xingang tianjin

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hebei, China

Brand Name FURUI

Model Number C BAND

Type Outdoor

Frequency Range 9750-12750

Specifications

satellite antennaFR-C-180-II FR-C-210-II FR-C-240-II

satellite antenna

Type	FR-C-180-II	FR-C-210-II	FR-C-240-II	FR-C-180-II	FR-C-210-II	FR-C-240-II
Parts	6parts	6parts	6parts	4parts	4parts	4parts
Caliber	180CM	210CM	240CM	180CM	210CM	240CM
C band gain4GHz	36dB	37.2 dB	38.39 dB	35.4 dB	36.8 dB	37.9 dB
F/D ratio	0.38	0.38	0.38	0.38	0.38	0.38
Focus distance	684MM	798MM	912MM	693MM	808MM	870MM
Material	Steel board	Steel board	Steel board	Screen mesh	Screen mesh	Screen mesh
Surface	Plastic polishing	Plastic polishing	Plastic polishing	Plastic polishing	Plastic polishing	Plastic polishing
Support	Many uses with	Many uses with	Many uses with	Many uses with	Many uses with	Many uses with
Angle of elevation	0-90	0-90	0-90	0-90	0-90	0-90
Level	Fixed/0-360	Fixed/0-360	Fixed/0-360	Fixed/0-360	Fixed/0-360	Fixed/0-360
Can receive	25m/sec	25m/sec	25m/sec	25m/sec	25m/sec	25m/sec
Can replace	40m/sec	40m/sec	40m/sec	40m/sec	40m/sec	40m/sec
Not damage	60m/sec	60m/sec	60m/sec	60m/sec	60m/sec	60m/sec
Ambient temperature	-40°C--+60°C	-40°C--+60°C	-40°C--+60°C	-40°C--+60°C	-40°C--+60°C	-40°C--+60°C
