Transcoder for IPTV System with IP& ASI input
Please add Tina skype: shineco.tina for direct discuss and more details.
Outline
Shineco SNK6026 is a professional bidirectional trans-coder to convert video between H.264 and MPEG-2 format and also to trans-code between HD and SD programs simultaneously. It is equipped with 6 tuner inputs to receive channels directly from satellite, or ASI /IP inputs to receive digital channels. After trans-coding, it outputs MPTS & SPTS through the DATA port or ASI port.
This trans-coder supports advanced re-multiplexing and can effectively provide operators with real-time code rate switch and optimize the video with its high performance.
It can be easily managed through web NMS system, and has become an ideal solution for operator to provide high quality video trans-coding.
Key Features
- Support 8*IP (SPTS/MPTS) input plus 6*tuners (or 6*ASI) input
- 4* tuners (or 4*ASI) input --- option 1
- Support 8*SPTS & 1*MPTS (UDP/RTP/RTSP) output; 1 ASI (MPTS) output
- Video Trans-coding: MPEG-2 SD/HD and H.264 SD/HD any-to-any
- Audio Trans-coding: AAC and MPEG-2 any-to-any or pass-through; AC3 pass through
- Support maximal 8 SD or 4 HD programs trans-coding
- Support maximal 8 channel audio trans-coding
- Support 1920x1080I, 1280x720P, 720x576i, 720x480i, 480x576, 544x576, 640x576 and 704x576 resolutions
- Supporti CBR and VBR rate control
- Support CC (closed caption)
- Advanced re-multiplexing
- LCD & Key board local control; web NMS management
Specification
Stream In |
MPTS/SPTS over UDP/RTP, 1000M BaseT Ethernet Interface/ SFP interface |
||
6 * (DVB-S/S2/C/T/ISDB-T/ATSC) Tuners; 6 * ASI (optional) | |||
4 * (DVB-S/S2/C/T/ISDB-T/ATSC) Tuners; 4 * ASI (optional) --- option 1 | |||
Video |
Resolution |
1920x1080I,1280x720P, 720x576i, 720x480i 480x576, 544x576, 640x576, 704x576 |
|
Trans-coding |
4*MPEG2 HD → 4*MPEG2/H.264 HD ; 4*MPEG2 HD → 4*MPEG2/H.264 SD ; 8 *MPEG2 SD → 8 *MPEG2/H.264 SD |
||
|
4* H.264 HD → 4*MPEG2/H.264 HD ; 4* H.264 HD → 4*MPEG2/H.264 SD ; 8* H.264 SD → 8 *MPEG2/H.264 SD | |||
Rate Control |
CBR/VBR |
||
Audio |
Trans-coding |
MPEG-1 Layer 2 to AAC any-to-any; AC3 pass through |
|
Sampling rate |
48KHz |
||
Bit Rate |
64Kbps-384Kbps |
||
Stream Out |
8*SPTS & 1*MPTS over UDP/RTP/RTSP, 1000M Base-T Ethernet Interface (UDP/RTP uni-cast / multicast) /SFP interface |
||
1*ASI (as a copy of one of the 8 SPTS or the MPTS) output, BNC interface | |||
System Function |
LCD & Key board control; web NMS management |
||
Ethernet software upgrade | |||
General |
Dimensions |
430mm×405mm×45mm(WxDxH) |
|
Approx weight |
4.8 Kg |
||
Temperature range |
0~45℃(Operation), -20~80℃(Storage) |
||
Power requirements |
AC 110V±10%, 50/60Hz or AC 220V±10%,50/60Hz |
||
Power consumption |
20W |
||
Principle Chart
Transcoding Example
Operation and Managment Page(Web Managment)
Connect the PC and the device with net cable, and use ping command to confirm they are on the same network segment.
