Specifications
digital surface roughness tester SRT5000easy operate
measurement Ra Rz Rq Rt
fast delivery
competitive price
Portable Digital digital surface roughness tester
Product Picture of digital surface roughness tester
product description
Appearance using pull aluminum mould design, durable,anti-electromagnetism interference ability significant, accord with current design new trend.
By using high-speed DSP processors for the data processing and calculation, measuring and calculation speed is greatly improved.
Liquid crystal adopts popular OLED display, high brightness, no perspective, wide temperature.It is suitable for various applications.
Using lithium ion rechargeable batteries, it can work long hours with no memory effect.It also can work with charging .Charging time is short,while the battery life is long.
Use the common USB interface to charge and communication .Use special charger or the computer USB port of chargeIt’s convenient and quick.
Dot matrix LCD display, interface message is rich.
Real-time monitoring of lithium battery power and display, electric charge and timely remind users.
Automatic shutdown function,low power consumption and hardware design make instrument working hours exceeds.It is suitable for all kinds of field use.
The sensors head has the protect door,which protect the head of the sensors effectively. Guarantee the accuracy of measurement.
SPECIFICATIONS:
Measurement Parameters(µm)Ra Rz Rq Rt
Stroke Length(mm)6
Sampling Length(mm)0.25 ,0.80 ,2.50
Evaluation Length(mm)1.25 ,4.0 ,
Measurement Range(µm )
Ra 0.05 ~ 10.0
Rz 0.1 ~ 50
Error of Indication±15%
Varation of Indication 12%
Touch needle tip arc radius and angle of the sensor
Tip arc radius10 µm±1 µm
Angle 90
The sensor touch needle static force measurement and its rate
Touch needle static force measurement ≤ 0.016N
Force measurement rate ≤ 800N/m
Sensor guide head pressure ≤ 0.5N
Battery:3.7V Lithium Ion battery
Contour Dimension106 mm×70 mm×24 mm
Weight 200g
Working Environment Conditions
Temperature -20°C~40°C
Relative Humidity < 90%
Surrounding no vibration and no corrosive medium.
Standard Accessories:
Main unit……………. ..1pc.
Carrying case…………1 pc.
Operation manual…….1 pc.
Standard sample plate 1 [c
Product certificate 1 pc
More Products for You to Choose
About us
Company Description
Huatec Group Corporation is a reliable supplier of nondestructive testing instrument in Beijing, China. We combine all the research and production advantage, take advantage of years' marketing and sales experience in global market, and contribute to offering most qualified competitive products and service to international markets from China.
Our products are composed of all kinds of metal and non-metal quality control equipments, such as portable hardness testers, micro vickers hardness testers, shore durometers, Rockwell hardness testers, Brinell hardness testers, portable X-ray flaw detectors, digital ultrasonic flaw detectors, coating/painting thickness gauges, ultrasonic thickness gauges, vibration testers, surface roughness testers, and profile projectors, and all of their accessories such as ultrasonic transducers, test blocks, and x-ray films.
