Specifications
LTLHM(R) Screw Compressors Ground Source Heat Pump-Wide range of application
-Green Products
-Stable and Reliable Operation
Energy Saving Ground Source Heat Pump Heating+Cooling+Free Life Hot Water
Water Source(Water to Water) Heat Pump(WSHP)
Ground Source Heat Pump(GSHP)
Geothermal Heat Pump(GHP)
MODELS: LTLHM(R)-35---LTLHM(R)-700
Heating Capacity: 142-2632KW
Cooling Capacity: 130-2340KW
Features:
Wide range of application:
Acting as multi-function unit such as cooling, heating, sanitary hot water separately or simultaneously. Wide application as hotel,
apartment, villa, factory, shopping center, office building, school, etc.
Green Products:
1. Adopting non-pollution and environment-friendly refrigerant; Great environmental and economic benefit: no boiler or cooling tower;
less space, less CO2 and less initial investment. Run-time without waste discharge, when heating replaces the boiler;
Stable and Reliable Operation:
2. Semi-hermetic screw compressor for mod. 185÷3700.Each compressor is equipped with a crankcase heater and a thermal overload
cut-out; the screw compressor is also complete with a built-in electronic protection with temperature sensor located directly in the
motor winding and on the discharge line.
3. The refrigerant circuit is complete with sight glass, filter drier, high and low pressure gauges, solenoid valve, direct expansion valve,
high and low pressure switch.
4. Shell and tube dry expansion type condenser, factory insulated with flexible close cell material. 4. Shell and tube type evaporator,
5. The electric panel consists of compressor breaker, compressor contactor, phase sequence relay, control circuit breaker,
microprocessor control with function display.
6. LCD display, touch screen control panel as standard.
7. Automatic operation dramatically reducing maintenance cost thanks to reliable microprocessor system.
8. For the units with semi-hermetic screw compressor, an infinitely variable capacity control system that is capable of exactly matching
the demand requirement of the system is to be supplied. This system is to provide precise and stable control of supply water temperature over the complete range of operating conditions.
High Efficiency and Energy Saving:
COP 4.5-5.5, low running cost, compare with other heating system can save 1/2-1/3.
Model Specification:
LTLHM(R)-35
LT---LVTE Company
L----Screw Compressor
H----Water to Water Heat Pump(Ground Source Heat Pump)
M---Standard Type
R----Units Type, R for Heat Pump(Heating and Cooling)
35---Normal Cooling Capacity(USTR)
Pictures in the factory
COMPANY AND FACTORY
1. National High-tech Enterprise, Abundant FinancialResources
Registered capital USD5,000,000, and as a new energy industry, we got financial support from government of
Shandong province. And we specializing in producing HVAC products (Heating, Ventilation and Air Conditioning) ,
including central air conditioning system, Air Handling Unit, Water Source HEAT PUMP, Ground Source HEAT PUMP,
and Refrigerant Equipments, including Air Cooled CHILLER, Water Cooled CHILLER,etc.
2. Two Production Bases, Guarantee Supply Ability.
Covering an area of 110,000 CBM workshop, annual production of heat pumps are 30,000 UNITS, chillers are
20,000 UNITS, andrefrigerant equipmentsare 50,000sets, fan coil 500,000 PCS.
3. Strong R&D Research Team
Built an Academician workstation, consisted of domestic famous professors and doctors, and high tech workman,
which can design projects according to customer’s requirement., And built long term cooperation relationship with
famous universities, such as Shandong university, Xi’an Jiaotong university, Qingdao ocean university.
4. Famous Brand Enjoyed High Reputation overseas
We are one of ten leading brands, product exported to Russia, Kazakhstan,
Ukraine, United States, Britain, Germany, Italy, and so on. And every year many overseas client come for a visit.
5. Perfect Quality Control System
Invested USD1,700,000 to build the enthalpydifference laboratory, imported advanced inspection equipments from
America, covering 100% testing item of AHRI, and with a perfect quality control system, from raw material purchase to
production and quality inspection, to ensure the high quality product can reach the international standards.
6. Qualified Export Certificate: CE certificate, and CRAA, ISO9001.
Every Year Attending Canton and Other Exhibitions
