Refrigeration Units Outdoor Unit Wall Mounted Commerical Air Cooler/Evaporator for Cold Room,Food&Vegerable Fresh&Quick Freezing

Refrigeration Units Outdoor Unit Wall Mounted Commerical Air Cooler/Evaporator for Cold Room,Food&Vegerable Fresh&Quick Freezing thumbnail-1
Refrigeration Units Outdoor Unit Wall Mounted Commerical Air Cooler/Evaporator for Cold Room,Food&Vegerable Fresh&Quick Freezing photo-1
US$ 296 - 1,598 MOQ: 5 Sets
Key Specifications
Get Latest Price
Type:
Other, D Series Air Cooler/Evaporator, Refrigeration Units D Series Air Cooler/Evaporator
Place of Origin:
Shandong, China
Brand Name:
LYTTE
Contact Supplier Request Quote Chat Now
Shandong Lvte Air Conditioning System Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Sea Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Other, D Series Air Cooler/Evaporator, Refrigeration Units D Series Air Cooler/Evaporator
Place of Origin Shandong, China
Brand Name LYTTE
Model Number D Series
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Air Cooler/Evaporator
-Outdoor Units
-Evaporator
-Refrigeration Units
-For Food Fresh,Quick Freezing and Cold Storage Room

High Efficiency Top Quality Refrigeratin Unit Outdoor Units Wall Mounted D Series Air Cooler/Evaporator for Food&Vegerable Fresh,Cold Storage Room and Quick Freezing

Introduction

D series Air Cooler/Evaporator is a kind of cooling equipments which used with refrigerant units application for different cold rooms. It is clasified three category including DL, DD, DJ by different cold room temperature. DL series applied for 0°Cpreservation cold room; DD series applied for about -18°C cold storage; DJ series applied for -25°C frozen storage.

Features

Unit Outcovering adopts high-quality steel, spraied the surface and corrosion resistance;Good appearance;

Coil adopted staggered permutation,and tighted to fit with Aluminum sheet to ensure high efficiency heat exchange;

Stainless steel electric heating tubes are uniformly distributed in the coil pipes, good defrosting effeciency;

Double water disk structure, which can effectively prevent the water tray freeze;

Model Specification

D   D   19/45   3   A

D--Products Series Code

D--Temperature(L:-5°C~5°C;D:-15°C~-20°C;J:Below -25°C)

19/45--Nominal heat exchange

3--Fan Diameter

A--Fan Quantity

A:380V/3P/50HZ;B:220V/1P/50HZ;C:220V/3P/60HZ;D:220V/1P/60HZ;E:110V/1P/60HZ(D,E Fan Diameter≤500mm)

Technical Data for D Series Air Cooler/Evaporator

DL Series(Fin Distance:4.5mm)    DL Series(Fin Distance:4.5mm)

Model Cooling Capacity KW
DT=7K T0=-7°C 		Area    Tube volume Air Flow Range Fan
Power		 Defrosting Power(KW)
R22 R404A m2 dm³ m³/h m W Coil Water wheel
DL2.2/311A 2.2 2.3 7 1.4 1500 9 90 1 0.5
DL3.5/311A 3.5 3.7 11 2.4 1500 9 90 1.5 0.5
DL4.7/312A 4.7 4.9 14 3.1 3000 9 180 1.8 0.9
DL6/312A 6 6.3 26 4.4 3000 9 180 2.7 0.9
DL9/352A 9 9.5 35 6.1 4500 10 280 2.7 0.9
DL12.5/402A 12.5 13.1 43 7.9 7000 13 360 3.6 1.2
DL14.5/402A 14.5 15.2 52 9.4 7000 13 360 4.8 1.2
DL17/402A 17 17.9 61 11 7000 13 360 6 1.2
DL25/502A 25 26.3 87 15.6 12000 17 900 7.5 1.5
DL29/453A 29 30.5 104 19.1 13500 17 750 8 2
DL36.5/503A 36.5 38.3 122 22.4 18000 19 1350 8 2
DL42/503A 42 44.1 156 25.6 18000 19 1350 10 2
DL49/503A 49 51.5 182 32 18000 19 1350 12 2
DL59/504A 59 62 208 38.7 24000 19 1800 13 2.6
DL70/554A 70 73.5 260 45.1 30000 25 2400 15.6 2.6
DL84/554A 84 88.2 306 58 30000 25 2400 18.6 2.6
DL103/604A 103 108.2 371 70.9 42000 25 3120 20.8 2.6
DL112/634A 112 117.6 390 77.3 46000 25 3200 23.4 5.2
DL122/634A 122 128.1 463 83.7 46000 28 3200 26 5.2



DL Series Overall Size&Installation Size:

Model Overall Size&Installation Size
A B C D E E1 E2 E3 F Pipe Diameter Drain
Pipe
Liquid In Air Return
DL2.2/311A 642 445 465 364 440 — — — 105 Φ12 Φ16 1"
DL3.5/311A 642 445 465 364 440 — — — 105 Φ12 Φ16 1"
DL4.7/312A 1092 445 465 364 860 — — — 120 Φ12 Φ22 1"
DL6/312A 1108 455 465 384 860 — — — 120 Φ12 Φ22 1"
DL9/352A 1408 455 465 384 1160 — — — 135 Φ16 Φ28 1"
DL12.5/402A 1488 555 565 474 1240 — — — 135 Φ16 Φ28 1"
DL14.5/402A 1488 555 665 474 1240 — — — 135 Φ16 Φ28 1"
DL17/402A 1488 555 565 474 1240 — — — 135 Φ16 Φ35 1"
DL25/502A 1758 595 665 474 1480 — — — 135 Φ16 Φ35 1"
DL29/453A 2121 595 665 474 1801 627 587 587 160 Φ22 Φ42 1"
DL36.5/503A 2400 595 665 474 2080 720 680 680 160 Φ22 Φ42 1"
DL42/503A 2704 595 665 474 2374 818 778 778 160 Φ22 Φ42 1"
DL49/503A 2704 655 665 534 2374 818 778 778 160 Φ28 Φ54 1"
DL59/504A 3938 785 675 654 3600 930 885 895 170 Φ28 Φ54 1"
DL70/554A 3938 785 775 654 3600 930 885 895 170 Φ28 Φ54 1"
DL84/554A 3938 785 975 654 3600 930 885 895 170 Φ28 Φ54 1"
DL103/604A 3938 785 975 654 3600 930 885 895 170 Φ35 Φ76 1"
DL112/634A 3938 785 1075 654 3600 930 885 895 170 Φ35 Φ76 1"
DL122/634A 3938 785 1175 654 3600 930 885 895 170 Φ35 Φ76 1"

 Products in Factory

Refrigeration Units Outdoor Unit Wall Mounted Commerical Air Cooler/Evaporator for Cold Room,Food&Vegerable Fresh&Quick FreezingRefrigeration Units Outdoor Unit Wall Mounted Commerical Air Cooler/Evaporator for Cold Room,Food&Vegerable Fresh&Quick FreezingRefrigeration Units Outdoor Unit Wall Mounted Commerical Air Cooler/Evaporator for Cold Room,Food&Vegerable Fresh&Quick FreezingRefrigeration Units Outdoor Unit Wall Mounted Commerical Air Cooler/Evaporator for Cold Room,Food&Vegerable Fresh&Quick Freezing
