professional supplier soybean oil expeller machine
- 20 Set / Sets per Month
- QINGDAO/SHANGHAI/TIANJIN PORT
- T/T Credit Card
- used for stone pe-250x400 quartz small jaw crushers
- low comsuption mini rock diesel engine jaw crusher
- china manufacturer provide used jaw crusher price
- high efficiency pe 400 x 600 old mini jaw crusher for sale
- manufacturer provide toggle platepe 150x250 jaw crusher machine
- pe 400x600 mobile jaw crusher price with spare parts
Product Details
Condition: | New | Usage: | Palm Oil | Type: | Other, Cold & Hot Pressing Machine |
Automatic Grade: | Automatic | Production Capacity: | 40Ton/hour | Place of Origin: | Henan, China |
Brand Name: | QIE | Model Number: | QIE-40 | Voltage: | 380V/440V |
Power(W): | 30KW | Dimension(L*W*H): | 1200*2800*1200mm | Weight: | 800Tons |
Certification: | CE/ISO | After-sales Service Provided: | Overseas service center available |
Product Description
professional supplier soybean oil expeller machine
Skype: recycle000
Mob: +8618790673640
Wechat/QQ ID: 1040179689
Customer visiting
Our factory fabrication ability
Our Certificates
Process specification
1. Fruit peeling and pressing process
Reception station:
A, The FFB bunches will be transported to factory by truck, after be weighted by weighting bridge, the FFB will be
loaded down to FFB Loading Ramp.
B, The iron door of unloading ramp is controlled by hydraulic device, Get the power from Hydraulic pump station.
Starting on the hydraulic device, iron door be lifted. FFB will fall down to the Palm Fruit screw conveyor, and transported
to pre-treatment plant, to Sterilizers.
Sterilizing process:
A, By Scraper Conveyor, FFB be transported to the top of sterilizing tank. Falling into sterilizing tank from feed inlet.
B, Sterilizing tank: The inside diameter of sterilizing tank is φ2000mm, length 12500mm, welded up by Q235B
material (Chemical composition:C0.12~0.2%,Si0.12~0.3%,Mm0.3~0.7%,P<0.045%,S<0.045%,Cr<0.3%,Ni<0.3%,
Cu<0.3%).
C, After FFB be transported into sterilizing tank (202), close the door of sterilizing tank, and open the vent valve behind
the tank, then saturated steam, which pressure is 3bar and temperature is about 130°
D. After all the cooling air have been discharged out,close vent valve, proceed to sterilizing section. Sterilizing takes
55~60minutes.
E, The time of sterilizing is also according the kind of FFB, if the pressure is too high or the time is too long , palm fruit
will be rot, also Resulting in the loss of oil, high temperature can change palm color.
F, Finish sterilizing process, close the steam valve, open the valve lead to Blow-off/down Silencer, can’t open the
sterilizing tank door until discharges out all steam and water.
G, Open the sterilizing tank door, sterilized FFB will fall on the FFB Scraper conveyor. Be transported to next station.
palm oil machine press:
A, The palm fruit is transported to Crush tank by fruit elevator.
B, The fruit in crush tank will be heated to 90~95°C, crush time is 10~20 minutes.
C, The pounded fruit flow into Palm fruit oil presser to press. Oil press cone can control cylinder,
working pressure is 50~70bar, revolving speed of presser main shaft is 12.5 r/min. Meanwhile the
mixture of crude palm oil and water Storage oil tank through crude oil groove. Then oil will be
pumped to Screening filte by oil pump. After filtering take out the oil foam, deposit impurities.
Palm oil flow into Passivating oil tank. The fiber cake and nucleus are exhausted from clearance
of cone head drop on Breaking cake auger.
Weighting---Reception--Sterilizing threshing-----Digesting----- Mashing---- Pressing ---- Depositing &Purification
----Filtering ----Palm crude oil
2. Palm kernel recycling and pressing process
Pressing cake ---- Crushing----Separating fiber&kernel ----- Crusher ----- Kernel&peel separator ----Kernel dryer
---- Drying kernel -----Crushing ----- Pressing
Quality and Service Commitment
Our company always put the interests of customers,product quality and service as first ,and always adhere
to the"no best, only better" as our purpose. We will be commitment to provide high quality products with perfect site services and after-sales service. Now the specific commitments are as follows:
1.Ensure provide complete sets of equipment and accessories timely.
2.Ensure that one-time installation debugging acceptance.
3.To provide high quality material with preferential price.
4.Priority to provide customer our new craftworks and products.
5.Free training technological operator to ensure the trained staff can operation independently.
6.In the installation process,we will appoint an installation supervision staff on the spot.
7.we will offer an experienced project manager, organize a good installation team for the work.
Contact Us
- Zhengzhou Qie Grain And Oil Machinery Co., Ltd.
- Contact nameAlly Lee
- Phone86-371-55606731
- AddressThe crossing of chemical industry road and Changchun road Zhengzhou,Henan
