50TPD SOYBEAN OIL EXTRACTION MACHINE INTRODUCTION
What can we supply to our customers?
1.Oil seed press:6YY Korea hydraulic sesame oil press, 6YL crew oil press and 6YT-5T oil
press unit.
2.Small top-grade cooking oil press unit, 1t-5t treated daily
3.Oil seed pretreatment: prepress unit, 10t-2000t treated daily
4.Oil seed extraction: 5t-1000t cake treated daily, adopting solvent(hexane) extraction.
5.Top-grade cooking oil and salad oil press unit, 5t-500t treated daily
6.First class oil refining unit: 5t-1000t crude oil treated daily
Customer visiting:
Application scope:
SOYBEAN OIL EXTRACTION MACHINE flowchart:
- Extraction section
Soybean cake →Extractor →Solvent spraying →Micella →Evaporation section →Cooling system
↓ ↓
Cake →Desolventization →Cooling system → → → Crude oil
↓
Meal →Meal packing
SOYBEAN OIL EXTRACTION MACHINE introduction:
Extraction process:
- Solvent pumps: continuously spray solvent to the rotary-type extractor
- Roary extractor: Spray and soak the prepressed cake with solvent so that oil fats can be disolved in solvent(form miscella). After processing, you can get wet meal and miscella (mixed oil)
- DTDC: usd to separate the solvent from the wet meal.
- Miscella tank 1st: pump the miscella (oil with solvent) in to the miscella 1st , then add saline water to it. The phospholipid in the miscella will react with the saline water, at last the reactant precipitate, reaching the goal of purifying.
- Miscella tank 2nd: the purified miscella will be pumped into it.
- Miscella stripping: it will remove the remaining solvent in miscella. And the solvent will be discharged to condenser for recycling.
- Condensers: to cooling the solvent gas separated from the wet meal and miscella for recycling.
SOYBEAN OIL EXTRACTION MACHINE advantage:
- Our products have the high quality and high performance.we use the stainless steel instead of the carbon steel.
- we buy directly from the manufacturer for guaranteeing the quality.
- our welding worker should get the certificates.and our electric machines all imported from Germany. And more other advantages we will talk in our specific condition.
Residual oil in meal |
≤1% (soybean cake ) |
Solvent consumption |
≤3Kg/T(hexane) |
Crude oil moisture and volatile matter |
≤ 0.30% |
Power consumption |
≤ 15KWh/T |
Steam consumption |
≤280Kg/T (0.8MPa) |
Finished meal moisture |
≤ 10-13% (adjustable) |
Residual solvent in finished meal |
≤ 300PPM (qualified detonated experiment |
Picture show of SOYBEAN OIL EXTRACTION MACHINE:
- Our company has been set up since 1982, It has been awarded the "The quality-star enterprise
of China"
- Our factoru is also a group enterprise integrating scientific research, manufacturing, sales as
one.
- We have cooperated with Research Institute of Machine Design Company and Henan, Henan
University of Technology (formerly the Zhengzhou Grain College) school-enterprise cooperation
in the oil equipment to carry out long-term, protein extraction, phospholipid extraction, etc.R & D
and application of new technologies.
- We have more than 200 employees ,among them ,there are 20 engineering technical personnel
who hold intermediate and senior professional titles, and two highly reputed professors.
- We have exported our machines to Moscow, Romania, Pakistan, India, Bangladesh, Thailand,
Indonesia, Nigeria, Malaysia, Tunisia, and so on. Our new customers can visit our demo machine
in different countries.
