Wheeled Tractor LYH864 Provided by Factory With Excellent Performance

Luoyang Lutong Heavy Industry Machinery Co., Ltd.
Wheeled Tractor LYH864 Provided by Factory With Excellent Performance thumbnail-1
Wheeled Tractor LYH864 Provided by Factory With Excellent Performance photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Qingdao/Tianjin/Other China Ports will also be OK
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 4WD
Usage Farm Tractor
Certificate CE
Brand Name LUTONG
Model Number LYH864
Place of Origin Henan, China

Specifications

WHEELED TRACTOR
CERTIFICATION: ISO&CE
DIESEL POWER: 66.2kw
TRCTION FORCE: 90horsepower
DRIVE: FRONT+ REAR DRIVE AXLE

Wheeled Tractor



Introduction

LUYANGHONG LYH864 wheeled trators, which are more advanced than the same types of machines in China, which are developed by LUOYANG LUTONG AGRICULTURAL EQUIPMENT LIMITED.



Main Features

This LYH864 Wheeled Tractor is very excellent is following areas:

  1. Adopt DONGFANGHONG diesel engines, better reliability, more back coefficient for torsion;
  2. Clutch with independent operation and double actions;
  3. Gear-box shows 4×(2+1), namely 8 forwards, 4 returns, if choosing climbing shift, then 16 forwards, 8 returns, shift in mesh;
  4. Driving force output device with postposition, peaceful and stable transmission, stronger bear the weight of loading;
  5. Adopt front-wheel turning with full liquid-pressure and independent oil way, turn agilely, reliably, power-saving;
  6. Adopt strong pressure lifter, independent oil supply, system performance reliable, multi-liquid output optional;
  7. The final driving is planet-gear style, smaller volume, bigger decelerating ratio;
  8. Istalled adjustable chair with elasticity and shock absorption, comfortable driving;
  9. The whole trator is beautiful, taste, modern, fashion.



Main Tech-Parameters

LYH864 Wheeled Tractor

Diesel Engine

Diesel model

Dongfanghong Engine 4108T86

Engine power

63.2kw

Weight

Structure mass

3750/3500kg(with cab/without cab)

The min. using mass

3990/3740kg(with cab/without cab)

Mass distribution(type with cab)

1640/2350kg ( front wheel /rear wheel )

Mass distribution(type without cab)

1600/2140kg ( front wheel /rear wheel )

Front loading

max.310kg

Rear loading

max.480kg

Parameters

Turning radius

5.6

Rated traction force

19.9KN

Speed range

0.46-36.9 km/h

Max. lifting force

>16KN (610mm behind the hanging point)

Front type spec.

11.2-24

Rear type spec.

16.9-34 /13.6-38(paddy field wheels)

Dimensions

Min. Ground clearance

379mm (low side for front driving bridge)

Wheelbase

2195mm

Front wheel tread

1610mm

Rear wheel tread

1620-2020mm (1620mm when they leave factory)

Overall dimension (L*W*H)

4396*2038*2810mm

Transmission System

1 Main Clutch

Clutch

double action

2 Gear Box

Gear box type

main and assistant shifs both are mesh with straight teeth

Gear Shift number

8F+4R or 16F+8R(if choosing climbing shift)

3 Rear Drive Axle

Rear drive axle central drive

Spiral bevel gear

Rear Differential Mechanism

close style, 4 bevel planet gears

Rear Differential Lock

mesh cover style

Rear drive axle final drive

single planet gear style, mount on the outside of the rear drive case’s both sides

4 Front Drive Axle

Front drive axle central drive

screw prick gear

Front Differential Mechanism

close style,2 bevel planet gears

Front drive axle final drive

single planet gear style

5 Transfer Case

Transfer Case

shift with column gear belt in straight teeth

Other System

Model of Parking brake

Handle operation, oil-bath style with multi-friction surface and machine compaction

Model of Running brake

Still hydraulic pressure, tray-style(double pieces), operate low-position pedal by human

Model of Traction device

Shift tow level, the place of the tow level can be adjusted

Model of Steering device

independent oil way, front-wheel turn with full hydraulic pressure

Model of Hanging device

Three point hanging with postposition

Control model of plough depth

place controlling /floating control /place adjusting as option



Guarantee time

One year or 1500 working hours, which comes fist afer the date of B/L.



Packing Tearms

Suitable for shipping, be protected against the potential damages.



Transportation

1*40 HQ  container is expected while shipping.



Wheeled Tractor LYH864 provided by factory with excellent performance
