NP-1903A Computerized-Controlled High-Speed Lockstitch Button Sewing Machine

NP-1903A Computerized-Controlled High-Speed Lockstitch Button Sewing Machine thumbnail-1
NP-1903A Computerized-Controlled High-Speed Lockstitch Button Sewing Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Industrial Sewing Machine
Place of Origin:
Zhejiang, China
Contact Supplier Request Quote Chat Now
Taizhou Narita Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Industrial Sewing Machine
Place of Origin Zhejiang, China
Brand Name NIPPON
Model Number NP-1903A
Stitch Formation Other, Button Attaching Machine
Mechanical Configuration Cylinder-Bed
Max. Sewing Speed 2700rpm
Max. Sewing Thickness 13mm
Stitch Length 10mm
Power 320W
Overall Dimensions 780 * 360 * 550mm
Feed Mechanism Manual
Certification CE

Specifications

Juki series 1903 button sewer machine
Computerized with panel,
With servo motor
Button clamp replacement is convenient

Computerized-Controlled High-Speed Lockstitch button sewing machine

NP 1903A

NIPPON BRAND

High-efficiency production Performance

The series realizes the globally maximum sewing speed of 2700rpm;

The high-speed performance allows quick sewing start and stop,and The high-speed thread trimming and high presser foot lifting speed significantly reduce the duration of sewing cycle.



Our bar tacking machine 1900A,control system can be exactly same with the original JUKI machine 1900A.  With perfect quality, the machine is very popular by our customers.



 1:Ensuring performance and productivity,sewing area, a wide variety of bar tack patterns can be realizing.



2: Set the tension of thread just according to control panel. Advanced dry-head and free oil,

    thread scatch mechanism, which prevent thread lose when start sewing.



3: The machine can make different patterns just according to the operation panel.



4: The computer controlled servo motor, direct driving motor make the machine can start and stop quickly,

   which reduce the cycle time by enhancing the cutting speed and press foot lift.



Specification

Model name

NP-1903A

Max. sewing speed

2,700rpm

Button size

Type: Round-shaped, flat button
Size: φ8~φ33mm

Stitch length

0.1~10mm (0.1mm step)

Lift of the work clamp

Max. 13mm

Number of
standard patterns

50 patterns

Number of data
that can be input

200 patterns (for up to 150 patterns, sewing data can be added)

Memory medium

EEP-ROM / EP-ROM

Button feed mode

Automatic feed mode,
non-feed mode,
and small-lot sewing mode

Needle

DP×18 (#14).

DP×5 (#11.#14)

DP×17 (#21.)



DETAIL OF MACHINE

NP-1903A Computerized-Controlled High-Speed Lockstitch button sewing machineNP-1903A Computerized-Controlled High-Speed Lockstitch button sewing machineNP-1903A Computerized-Controlled High-Speed Lockstitch button sewing machine



NP-1903A Computerized-Controlled High-Speed Lockstitch button sewing machineNP-1903A Computerized-Controlled High-Speed Lockstitch button sewing machine
