Dubai Lnb Price

Dubai Lnb Price photo-1
Dubai Lnb Price photo-2
Dubai Lnb Price photo-3
Dubai Lnb Price photo-4
Dubai Lnb Price photo-5
Dubai Lnb Price photo-6
US$ 1.3 - 1.5 MOQ: 5000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
OEM
Model Number:
u112-5
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name OEM
Model Number u112-5

dubai lnb price



Product Description



Input Frequency Range

LOW Band:10.7~11.7GHz



High Band:11.7~12.75GHz

Output Frequency Range

Low Band: 950 - 2050MHz



High Band: 1100 - 2150MHz

Input VSWR

2.5:1

Output VSWR

2.5:1

L.O. Frequency

Low Band 9.75GHz



High Band 10.6GHz

L.O. Stability

±2MHz @ (-40c~70c)

L.O. Phase Noise

-70dBc/Hz (1KHz Offset)



-90dBc/Hz (10KHz Offset)



-110dBc/Hz (100KHz Offset)

Conversion Gain

60dB (TYP)

Gain Flatness

±0.5dB/6MHz; ±2.5dB/IN BAND

Noise Figure

±0.3dB (Typ)

Image Rejection

50dB(Typ)

Output Power

+5dB (Min) (at 1dB gain compression)

Cross Polarization Discrimination

23dB(Min)

DC SUPPLY VOLTAGE

11~14.5V (V),15.5~22V (H)

SUPPLY CURRENT

130mA (MAX)

LOW/HIGH BAND SWITCHING

Low Band: 0Hz

HIGH BAND: 22KHz±4KHz

Output Connector

75Ω "F" type female

RELATIVE HUMIDITY

0%~95%

Operating Temperature

-30 °C to +70 °C

 dubai lnb price





Packaging & Shipping

 by carton,100 pcs in one carton.

ship by air or by sea,20-25 days can send out the lnbs after getting your payment.







Company Information

 we are X Square techonology,in lnb fields we work very hard to improve our quality and lower the price.

we are confident to promise you our lnb with good quality and compectitive price.

maybe you would ask : "really?" if you doubt us, why don't you come to check with us,we will give you surprise,thank you.

dubai lnb price
