7Ton Mini Excavator (LT70)

FOB Price

US$ 40,000 - 41,000 / Unit

1 Unit(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Henan, China	Brand Name	LUTONG
Model Number	LT70-6	Condition	New
Moving Type	Crawler Excavator	Operating Weight	6800kg
Bucket capacity	0.24m3	Maximum Digging Height	5752mm
Maximum Digging Depth	4022mm	Machine Weight	7000Kg
Max Digging Radius	6387mm	After-sales Service Provided	Engineers available to service machinery overseas

1.Original imported Cummins B3.3 diesel engine;
2.Bucket capacity:0.26~0.3m3;
3.Hydraulic operation.

LT70-6 Crawler Excavator

Technical parameters:

Model			LT70-6
Bucket capacity		m3	0.24
Operating weight ---including boom & arm & bucket & operator & lubricant & coolant liquid & full fuel tank		kg	6800
Dimension (in transportation)	Overall length	mm	6,230
	Overall width	mm	2,060
	Overall height	mm	2,780
	Min. clearance	mm	350
Engine	Model	Japan Original Imported Cummins B3.3
	Type	Water-cooled, DI, 4-stroke
	No. of cylinders	4
	Bore x Stroke	95mm x 115mm
	Total displacement	L	3.3
	Rated output power	KW/rpm	44.1/2200
	Peak torque	N.m/rpm	214/1600
Digging performance	Max. digging height	mm	5,752
	Max. dumping height	mm	4,063
	Max. digging depth	mm	4,022
	Max. digging radius	mm	6,387
	Max. bucket digging force	kg	3800
Hydraulic system	Main pump	piston pump X 2 + gear pump X 1
	Max. displacement	ml/r	66.2
	Max. pressure
	Boom & arm & bucket	Mpa	22
	Driving system	Mpa	22
	Swing system	Mpa	21
	Control system	Mpa	4
	Pilot pump	Gear pump
	Main valve	9-set Multi-way valve
Travel system	Travel motor	Dual-speed independent piston motor
	Brake system	Spring-loaded multi-disc hydraulic brake
	Travel speed (Gear I/II)	km/h	4.6/2.8
	Max. output torque	KN	8.5
	Grade ability	°/%	35°/70%
	Track shoe width	mm	400 (standard)
	Ground pressure	Kpa	38
	Track length ( chassis)	mm	2,550
	Track wheel base	mm	1,990
	Track gauge	mm	1,660
Bulldozing plate	Bulldozing plate width	mm	2,100
	Bulldozing plate height	mm	420
	Operating distance(lifting up/down)	mm	370/350
Capacity	Fuel tank capacity	L	128
Capacity	Hydraulic oil tank capacity	L	75
