Specifications
1.Cold screw oil press machine2.Cottonseed oil, castor oil,etc.
3.With engineering guidance
4.Low consumption
5.ISO900, CE.
Mature technology cold screw oil press machine with ISO&CE
Mature technology cold screw oil press machine with ISO&CE Construction features:
6YL series spiral oil press is mainly composed of 7 major parts of screw axis, press cage, feed mechanism, cake yielding mechanism. transmission system, electric control part and vacuum filter part. All the parts are assembled on the frame and screwed as a whole.
Mature technology cold screw oil press machine with ISO&CE Main Characters:
1.Saving labor: it can save 60% labor for equal output and 40% labor cost per day for one or two people are able to make production.
2.Widely-used: it can be used to completely press more than 20 kinds of oil crops, such as peanuts, sesame, vegetable seeds, soybean, oil sunflower and flax by third levels for one time.
3.Pure oil quality: the vacuum oil filtering is used to remove residue so as to ensure the pure oil quality and meet the standard of health quarantine.
4.Small land-using: an area of 10-20 m2 workshop can meet the need of production.
Mature technology cold screw oil pres machine with ISO&CE Main parameters:
Model |
6YL-80 |
6YL-100 |
6YL-120 |
6YL-130 |
6YL-160 |
Screw speed |
30-45r/min |
30-40 r/min |
30-40 r/min |
28-40 r/min |
28-40 r/min |
Gear ratio |
14/42x19/57=1:6.63 |
15/40x15/55=1:9.78 |
15/34x15/55=1:9.59 |
15/38x19/48=1:7.38 |
15/38x15/52=1:8.78 |
Dimension |
1650x1150x1750 |
1950x1300x1900 |
2050x1350x2000 |
2200x1600x2150 |
2500x1600x2500 |
Productivity |
80-150kg/h |
150-250kg/h |
200-300kg/h |
250-400kg/h |
450-600kg/h |
Power |
Y160L-6-5.5KW |
Y160M-6-7.5KW |
Y160L-6-11KW |
Y180L-6-15KW |
Y200L-6-18.5KW |
Vacuum pump |
Y90S-4-0.55KW |
Y90S-4-1.1KW |
Y100L1-4-1.5KW |
Y100L1-4-2.2KW |
Y100L1-4-2.2KW |
Heater |
2KW |
3KW |
3.3KW |
3.8KW |
4KW |
