Fe Battery Powder Grinding and Classifying Machine With Advance Technology

Fe Battery Powder Grinding and Classifying Machine With Advance Technology thumbnail-1
Fe Battery Powder Grinding and Classifying Machine With Advance Technology thumbnail-2
Fe Battery Powder Grinding and Classifying Machine With Advance Technology thumbnail-3
Fe Battery Powder Grinding and Classifying Machine With Advance Technology thumbnail-4
Fe Battery Powder Grinding and Classifying Machine With Advance Technology thumbnail-5
Fe Battery Powder Grinding and Classifying Machine With Advance Technology thumbnail-6
Fe Battery Powder Grinding and Classifying Machine With Advance Technology photo-1
Fe Battery Powder Grinding and Classifying Machine With Advance Technology photo-2
Fe Battery Powder Grinding and Classifying Machine With Advance Technology photo-3
Fe Battery Powder Grinding and Classifying Machine With Advance Technology photo-4
Fe Battery Powder Grinding and Classifying Machine With Advance Technology photo-5
Fe Battery Powder Grinding and Classifying Machine With Advance Technology photo-6
US$ 8500.00 - 8500.00 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Pulverizer
Product Type:
Fertilizer
Contact Supplier Request Quote Chat Now
Qingdao Shina Machinery Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Pulverizer
Product Type Fertilizer
Place of Origin Shandong, China
Brand Name SHINA
Model Number QWJ
Voltage Customized
Power(W) 0.55-11KW
Dimension(L*W*H) Customizable
Weight Weight
Certification CE ISO
Warranty 12 Months
After-sales Service Provided Engineers available to service machinery overseas
Product Description



Process:


Air Jet Mill consisting of fluid bed opposed jet mill with integrated turbo classifier(s) for highest applications               with best top cut and steep particle size distribution.


There are a variation of application as mainly:grinding,classifying,homogenisation,selective operation,drying,                   surface treatment,and many others.

The fluid bed opposed jet mill can be combined with single wheel classifiers or multi-wheel classifier.


Feature of Air Jet Mill:


- Fluidbed opposed jet principle

- Loss in weight system

- Products free of oversize

- Steep particle size distribution

- Multifunction


- Special nozzle configuration

-Cryogen, inert, hot gas solutions

- Laboratory system available

- Contamination free processing

- Integrated turbo classifier as single wheel or multi-wheel

Technical Data:

TECHNICAL DATE
                Parameters
Type
Product Fineness
D97: μm
Grinding Air
m3/min
Air Pressure
Mpa
Motor Output
KW
QWJ03
3~100
3
0.7~1.0
3
QWJ06
3~100
6
0.7~1.0
6
QWJ10
3~100
10
0.7~1.0
4
QWJ20
3~100
20
0.7~1.0
5.5/7.5
QWJ40
3~100
40
0.7~1.0
15
QWJ60
3~100
60
0.7~1.0
18.5
QWJ80
3~100
80
0.7~1.0
5.5*4/22
QWJ120
3~100
120
0.7~1.0
15*3
QWJ160
3~100
160
0.7~1.0
15*4
QWJ240
3~100
240
0.7~1.0
15*6
QWJ320
3~100
320
0.7~1.0
30*3

Note: 1. Capacity depends on material properties and final product fineness

             2. Product Fineness is adjustable according to different technical data


Main Machine(Referrence: air jet mill QWJ20 ) With Detailed Photos:


Layout
Customer Referrence

Name: Air Jet Mill QWJ10

Name of feed material: Chemical etc
Place: Turkey
Installation Time: Jan.. 2014

Name: Air jet Mill QWJ 20

Name of feed material: Polishing Powder
Place: VietNam
Installation Time: Feb. 2016

Name: Air Jet Mill QWJ40

Name of feed material: Talc
Place: Pakistan
Installation Time: March. 2008

Name: Air Jet Mill QWJ120

Name of feed material: Medicine
Place: Guangxi , China
Installation Time: Aug. 2014

Name: Air Jet Mill QWJ20

Name of feed material: Toner
Place: Shandong , China
Installation Time: Jan.. 2009

Name: Air Jet Mill QWJ60

Name of feed material: Food
Place: Korea
Installation Time: March. 2015

Name: Air Jet Mill QWJ20

Name of feed material: Rare earth Polishing Powder
Place: Taian , China
Installation Time: Sept.. 2010
